Buy Schurter 0031.2500 0031.2500 Fuse holder Suitable for Micro fuse 6.3 x 32 mm 1 pc(s)

Black cylindrical network switch with metal casing, side-mounted connection pins and a round push button.

Image similar

Product type

Fuse holder

Mounting type

PCB mount

Suitable for

Micro fuse 6.3 x 32 mm

Connection

Solder pins

Material

Duroplast

Datasheet (PDF)

Unavailable

15 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Schurter high-current fuse holder

Our service for you

Technical specifications

Series FUP
Dimensions: Height 63 mm
Approvals: CULus,VDE
Design: Closed
Mounting: PCB mounting
Mounting: Plug connection
Contact material: Tin-plated copper alloy
Applications: For G-fuses 5x20 mm and 6.3x32mm
Housing material: Duroplast (UL94V-0)
Identification: Logo, type, nominal voltage, nominal power, rated current, Test mark
Colour, black
Connection type: Soldering pins
Diameter 22 mm
Weight 14.6 g
Min. Operating temperature range -40 °C.
Operating temperature range, max. 85 °C.
Rated current 16 A
Dielectric strength 3 kV
Surge voltage resistance: 4 kV
NOMINAL VOLTAGE V AC 500 V AC
Contact resistance max. 10 mOhm
Insulation resistance 10 MOhm
Nominal power intake 4 W
Soldibility 245 °C / 2 s
IEC 61140 standard
IP40 with cover cap
Contact protection category: PC2

Product type: Fuse holder

Connection: Solder pins

Material: Duroplast

Mounting type: PCB mount

Suitable for: Micro fuse 6.3 x 32 mm

Touch protection type: PC2

Weight: 14.60 g

Min. temperature: -40 °C

Max. temperature: 85 °C

Height: 63.00 mm

(Ø): 22.00 mm

Content: 1 pc(s)

Dim: (Ø x H) 22.00 mm x 63.00 mm

RoHS-compliant: Yes

Type: 0031.2500

Certification marks: IEC 61140

Documents & Downloads

Datasheet

Datasheet 3156559 Schurter 0031.2500 0031.2500 Fuse holder Suitable for Micro fuse 6.3 x 32 mm 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3156559 Schurter 0031.2500 0031.2500 Fuse holder Suitable for Micro fuse 6.3 x 32 mm 1 pc(s)

Description

• Closed high-current fuse holders with 16A (VDE), 30A (UL)
• For 6.3x32mm fuse
• Slot for screwdriver, horizontal
• Solder connections for PCB mounting
• Protection class IP40 (according to IEC60536)
• Soldibility: 2455°C / 3s

This text is machine translated.
