Buy Schurter 0031.3703 0031.3703 Fuse holder Suitable for Micro fuse 5 x 20 mm 1 pc(s)

Black adapter with Euro and US plugs. Used for connecting electronic devices to different socket standards.

Image similar

Product type

Fuse holder

Mounting type

PCB mount

Suitable for

Micro fuse 5 x 20 mm

Connection

Solder pins

Material

Thermoplastic

Datasheet (PDF)

Fast track dispatch on Wed, 30 Sep

17 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 4.61 / piece)

€ 4.61

plus VAT.

14-day return policy included

Report legal concerns

Highlights & Details

Schurter high-current fuse holder

Our service for you

Technical specifications

Series FAF
Dimensions: Height 38.4 mm
Approvals: CULus,VDE
Design: Closed
Mounting: PCB mounting
Contact material: Tin-plated copper alloy
Applications: For G-fuses 5x20 mm
Housing material: Thermoplastic (UL 94V-0)
Identification: Logo, type, nominal voltage, nominal power, rated current, Test mark
Colour, black
Connection type: Soldering pins
Diameter: 12.5 mm
Weight 5.03 g
Min. Operating temperature range -40 °C.
Operating temperature range, max. 85 °C.
Rated current 6.3 A
Dielectric strength 3 kV
Surge voltage resistance: 4 kV
NOMINAL VOLTAGE V AC 250 V AC
Contact resistance max. 10 mOhm
Insulation resistance 10 MOhm
Nominal power intake 2 W
Soldibility 245 °C / 3 s
IEC 61140 standard
Insulation class IP40
Contact protection category: PC2

Product type: Fuse holder

Connection: Solder pins

Material: Thermoplastic

Mounting type: PCB mount

: IP40

Suitable for: Micro fuse 5 x 20 mm

Type: sickened

Touch protection type: PC2

Weight: 5.03 g

Min. temperature: -40 °C

Max. temperature: 85 °C

Height: 38.40 mm

(Ø): 12.50 mm

Dimensions: 38.4 mm

Content: 1 pc(s)

Dim: (Ø x H) 12.50 mm x 38.40 mm

RoHS-compliant: Yes

Type: 0031.3703

Certification marks: IEC 61140

Documents & Downloads

Datasheet

Datasheet 3156561 Schurter 0031.3703 0031.3703 Fuse holder Suitable for Micro fuse 5 x 20 mm 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3156561 Schurter 0031.3703 0031.3703 Fuse holder Suitable for Micro fuse 5 x 20 mm 1 pc(s)

Description

• Closed fuse holder for currents of 6.3A (VDE)
• For 5x20mm fuses
• Slot for screwdriver, standing
• Material cap: Thermoplastic, black, UL 94V-0
• Solder connections for PCB mounting
• Protection class IP40 (according to IEC 61140)
• Soldibility: 245°C / 3s
• Suitable for devices of protection class I according to IEC61140
