Schurter 3-132-192 EMI filter 250 V 15 A (L x W x H) 25.6 x 48.6 x 24.6 mm 1 pc(s) Piece
Part number:
Item no:
Packaging type
Piece
Product type
EMI filter
Connection
Braid
Nominal voltage
250 V
Nominal current - rounded value
15 A
Datasheet (PDF)
Highlights & Details
Line filter 5121 IEC C14 10A Fl. schrader. L.
- Compact IEC C14 connector filter
- Optimum shielding through completely closed filter casing
- V-Lock extract safety device
- According to IEC also 10A is possible
- With wire connection 150 mm
Technical specifications
- Series 5121
- Contact resistance, max. 2.2 nF
- Mounting type: Panel mounting
- Dielectric strength 2NO, conductor/earth 2.7 kV DC
- Dielectric strength 2NO, conductor/conductor 1.7 kV DC
- Climate category HPF (25/085/21)
- Protection: front IP40
- Packaging type
Piece
- Product type
EMI filter
- Connection
Braid
- Capacity (elec.)
2.2 nF
- Nominal voltage
250 V
- Nominal current
15 A
- Nominal current - rounded value
15 A
- Leakage current
0.5 mA
- Shielding
Full shielding
- Length
25.6 mm
- Width
48.6 mm
- Height
24.6 mm
- Min. temperature
25 °C
- Max. temperature
85 °C
- Certification marks
IEC 60320-1; IEC 60939; UL 60320-1; UL 60939-3; CSA C22.2 NO. 42; CSA C22.2 NO. 8; IEC 62368-1; UL 62368-1
- Manufacturer part #
3-132-192
- Type
3-132-192
- Content
1 pc(s)
- Dim
(L x W x H) 25.6 x 48.6 x 24.6 mm
- RoHS-compliant
Yes
- Operating temperature (max.)
85 °C
- Operating temperature (min.)
-25 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3738214 Schurter 3-132-192 EMI filter 250 V 15 A (L x W x H) 25.6 x 48.6 x 24.6 mm 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3738214 Schurter 3-132-192 EMI filter 250 V 15 A (L x W x H) 25.6 x 48.6 x 24.6 mm 1 pc(s) Piece
Description
Schurter IEC-filter 5121 panel mounting 250V 15A IP40
