Schurter 4400.0034 4400.0034 RCCB 1 pc(s)
EAN:
Part number:
Item no:
Product type
RCCB
Type
16 A
Connection
Type C CEE 7/16 plug 0.8 mm
Min. temperature
-5 °C
Max. temperature
60 °C
Datasheet (PDF)
Technical specifications
- Series T11-611
- Dimensions: Length 24 mm
- Dimensions: Width 14 mm
- Dimensions: Height 48.2 mm
- Nominal current: 16 A
- Approvals: CULus, VDE, CE
- Mounting: Front panel mounting
- Snap-in fastening
- Trigger type: Positive release
- Applications: Power tools, household appliances, mains and chargers, industrial applications, etc.
- Connection type: Spade connector 6.3x0.8 mm
- Weight: 10 g
- Board thickness, min. 0.8 mm
- Board thickness, max. 3 mm
- Min. Operating temperature range -5 °C.
- Operating temperature range, max. 60 °C.
- Service life, type: 500 circuits
- Shock resistance 100 g
- Switching rating 96 A
- Limited switching capacity 2,000 A.
- Voltage resistance 1,500 V
- NOMINAL VOLTAGE V AC 240 V AC
- NOMINAL VOLTAGE V DC 48 V DC
- Insulation resistance 100 MOhm
- IEC 60934 standard
- Product type
RCCB
- Type
16 A
- Connection
Type C CEE 7/16 plug 0.8 mm
- Min. temperature
-5 °C
- Max. temperature
60 °C
- Length
24.00 mm
- Width
14.00 mm
- Height
48.20 mm
- Durability
500 circuits
- Content
1 pc(s)
- Type
4400.0034
- Dim
(L x W x H) 24.00 x 14.00 x 48.20 mm
- RoHS-compliant
Yes
- Breaking capacity
96 A
- Certification marks
IEC 60934
- Weight
10.00 g
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3156971 Schurter 4400.0034 4400.0034 RCCB 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3156971 Schurter 4400.0034 4400.0034 RCCB 1 pc(s)
Description
• Thermal single-pole device protection switch
• Ideal replacement for fuse holders with fuse block, especially for higher nominal currents
• No replacement fuse necessary, can be reset quickly
• Insensitive to switch-on tips
• Snap-in mounting for front panel thickness 0.8...3mm
• Spade connector 6.3x0.8 mm
This text is machine translated.
• Ideal replacement for fuse holders with fuse block, especially for higher nominal currents
• No replacement fuse necessary, can be reset quickly
• Insensitive to switch-on tips
• Snap-in mounting for front panel thickness 0.8...3mm
• Spade connector 6.3x0.8 mm
