Image similar
Schurter 7010.9880.63 7010.9880.63 SMD fuse (Ø x L) 2 mm x 7.00 mm 5.00 A 125 V DC Quick response -F- Content 1 pc(s)
EAN:
Part number:
Item no:
Product type
SMD fuse
Nominal voltage
125 V DC
Nominal current - rounded value
5 A
Release characteristics
Quick response -F-
Length
7.00 mm
Datasheet (PDF)
Technical specifications
- Series 172876
- Dimensions: Length 7 mm
- Nominal voltage at 50/60Hz 125 V DC
- Nominal current 5 A
- Approvals CE, cULus
- Trigger time: Quick-action
- Contact material: Tin-plated copper alloy
- Casing material: Ceramic
- SMD connection type
- Material: Copper alloy, tin plated
- Diameter 2 mm
- Weight: 0.07 g
- Min. Operating temperature range -55 °C.
- Operating temperature range, max. 125 °C.
- Climate category IEC 55/125/56
- Melting Integral: 4 A²/s.
- Rated breaking capacity 300 A.
- NOMINAL VOLTAGE V AC 63 V AC
- Voltage drop 125 mV
- Loss rating, max. 625 mW
- Soldibility 235 °C / 20 s
- UL 248-14 standards
- Product type
SMD fuse
- Nominal voltage
125 V DC
- Dim
(Ø x L) 2 mm x 7.00 mm
- Nominal current
5.00 A
- Nominal current - rounded value
5 A
- Release characteristics
Quick response -F-
- Length
7.00 mm
- (Ø)
2 mm
- Certification marks
UL 248-14
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
7010.9880.63
Documents & Downloads
Datasheet
Datasheet 3306323 Schurter 7010.9880.63 7010.9880.63 SMD fuse (Ø x L) 2 mm x 7.00 mm 5.00 A 125 V DC Quick response -F- Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3306323 Schurter 7010.9880.63 7010.9880.63 SMD fuse (Ø x L) 2 mm x 7.00 mm 5.00 A 125 V DC Quick response -F- Content 1 pc(s)
Description
SMD fuse
Quick-blow
Made from ceramic substrate
High breaking capacity
Directly solderable on PCB
This text is machine translated.
Quick-blow
Made from ceramic substrate
High breaking capacity
Directly solderable on PCB
This text is machine translated.
