Image similar
Image similar
Schurter 8020.5081 8020.5081 Micro fuse (Ø x L) 6.3 mm x 32 mm 20.00 A 63 V DC Quick response -F- Content 1 pc(s) Single
EAN:
Part number:
Item no:
Packaging type
Single
Product type
Micro fuse
Nominal voltage
63 V DC
Nominal current - rounded value
20 A
Release characteristics
Quick response -F-
Datasheet (PDF)
Technical specifications
- Series SHF
- Nominal voltage at 50/60Hz 63 V DC
- Nominal current 20 A
- Approvals: CULus,CE
- Trigger time: Quick-action
- Contact material: Nickel-plated copper alloy
- 6.3 x 32 mm case
- Applications: As primary protection in devices
- Casing material: Ceramic
- Weighs 2.84 g.
- Min. Operating temperature range -40 °C.
- Operating temperature range, max. 85 °C.
- Climate category IEC 40/85/21
- Melting Integral: 1,350 A²/s.
- Rated breaking capacity 1,500 A.
- NOMINAL VOLTAGE V AC 440 V AC
- Voltage drop 130 mV
- Power loss, max. 9.5 W.
- UL 248-14 standards
- Packaging type
Single
- Product type
Micro fuse
- Nominal voltage
63 V DC
- Dim
(Ø x L) 6.3 mm x 32 mm
- Nominal current
20.00 A
- Nominal current - rounded value
20 A
- Switch-off capacity
1.500 A
- Release characteristics
Quick response -F-
- Fuse layout
Ceramic tube
- Length
32 mm
- (Ø)
6.3 mm
- Certification marks
UL 248-14
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
8020.5081
Documents & Downloads
Datasheet
Datasheet 3306231 Schurter 8020.5081 8020.5081 Micro fuse (Ø x L) 6.3 mm x 32 mm 20.00 A 63 V DC Quick response -F- Content 1 pc(s) Single
User & Safety Instructions
User & Safety Instructions 3306231 Schurter 8020.5081 8020.5081 Micro fuse (Ø x L) 6.3 mm x 32 mm 20.00 A 63 V DC Quick response -F- Content 1 pc(s) Single
Description
G fuse
Suitable for: 3-phase applications, DC applications, power supplies, frequency converters and power electronics
High breaking capacity ≥ 1500A
This text is machine translated.
Suitable for: 3-phase applications, DC applications, power supplies, frequency converters and power electronics
High breaking capacity ≥ 1500A
This text is machine translated.
