SCI 149777 LED indicator light Yellow 2 V 20 mA 200 mcd
EAN:
Part number:
Item no:
Product type
LED indicator light
Forward voltage U(F)
2 V
Forward current I(F)
20 mA
Recess diameter
8.2 mm
Light intensity I(V)
200 mcd
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
3
-
€ 1.08
10
7% = € 0.08
€ 1.00
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 1.08 / piece)
€ 3.24
plus VAT.
Highlights & Details
SCI 149777 LED indicator light Yellow 2 V 20 mA 200 mcd
Our service for you
Technical specifications
- Lens: clear
- Product type
LED indicator light
- Type
R9-104L-12-Y
- Factory colour
Yellow
- Forward voltage U(F)
2 V
- Forward current I(F)
20 mA
- Recess diameter
8.2 mm
- Front panel thickness
max 5 mm
- Case colour
Chrome
- Material
Brass
Rubber
- Material properties
shiny
- Mounting type
Screw
- Light intensity I(V)
200 mcd
- Radiation angle
15°
- LED features
Built-in reflector
LED 5 mm
- Connection
Soldering
- Min. temperature
-25 °C
- Max. temperature
85 °C
- RoHS-compliant
Yes
- Type
5 mm LED-inner reflector
- Content
1 pc(s)
- Material (details)
Chrome-plated brass/ rubber
- Operating temperature
-25 - +85 °C
- Operating voltage
-
Documents & Downloads
Datasheet
Datasheet 149777 SCI 149777 LED indicator light Yellow 2 V 20 mA 200 mcd
