Highlights & Details
SecoRüt Voltage limiter No. of cores 7
- Short-circuit and overload protection
- Sealed electronics
- 0 mA own current consumption
Technical specifications
- Dim
(L x W) 18.5 cm x 7.8 cm
- Product type
Voltage limiter
- No. of cores
7
- Type
Voltage reducer
- Width
7.8 cm
- Length
18.5 cm
- Operating voltage
24 v
Documents & Downloads
Datasheet
Datasheet 852207 SecoRüt Voltage limiter No. of cores 7
User & Safety Instructions
User & Safety Instructions 852207 SecoRüt Voltage limiter No. of cores 7
Information
Information 852207 SecoRüt Voltage limiter No. of cores 7
eNum certificate
eNum certificate 852207 SecoRüt Voltage limiter No. of cores 7
Description
This voltage reducer allows you to run a 12 V trailer on a 24 V tow vehicle effortlessly and without structural modifications. The voltage reducer is of :7pin 24 V power outlet on a 7-pin N type. 12 V plug.
The towing vehicle has a 7-pin. 24 V socket type N, the trailer has a 7-pin. 12 V power to DIN / ISO 1724th
The towing vehicle has a 7-pin. 24 V socket type N, the trailer has a 7-pin. 12 V power to DIN / ISO 1724th
Features
- 0 mA with open output no power consumption
- 6 x 70 W total max. 260 W lamp power
- Protected against overcurrent and excess temperature
- Flanged box with hinged lid
Hints
Only for incandescent lamps and LEDs with ballast adapter
The trailer warning light does not respond to the mechanical indicator
