Self Electronics SLT30-48VLG-ES LED driver Constant voltage 30 W 0 A - 625 mA 48 V DC not dimmable, Suitable for flammab
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
SELF ELECTRONICS LED SWITCHED-MODE POWER SUPPLIES SLT30-48VLG-ES
- Constant voltage
- 48 V DC
- 0 A - 625 mA
Technical specifications
- Product type
LED driver
- Type
Constant voltage
- Dim
(L x W x H) 165 x 40 x 30 mm
- Factory colour
Grey
Blue
- Output voltage (max.)
48 V DC
- Test mark
MM · SELV
- Max. output current
625 mA
- Output current (max.) - rounded
625 mA
- Operating voltage
230 V AC
- Protection class
II
- LED driver features
not dimmable
Suitable for flammable surfaces
Approved for use on furniture
Surge protection
Overvoltage
IP20
- Connection
Screw terminal
- Max. power
30 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
0 A
- Input voltage (max.)
264 V AC
- Min. input voltage
198 V AC
- Weight
200 g
- Power range
30 W (max)
- Type
Pulsed
- Width
40 mm
- Height
30 mm
- Length
165 mm
- Max. temperature
+50 °C
- Min. temperature
-20 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2176613 Self Electronics SLT30-48VLG-ES LED driver Constant voltage 30 W 0 A - 625 mA 48 V DC not dimmable, Suitable for flammab
User & Safety Instructions
User & Safety Instructions 2176613 Self Electronics SLT30-48VLG-ES LED driver Constant voltage 30 W 0 A - 625 mA 48 V DC not dimmable, Suitable for flammab
Description
Features
- Independant operating device
- Protection class II, SELV output
- Constant voltage
- IP20
- Protected against overload, short circuit, overvoltage and temperature protection
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
