Self Electronics SLT350-48VLC-UN LED driver 350 W 48 V 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
SLT350-48VLC-UN
- 48 V
Technical specifications
- Efficiency:94% input current 1.7 A
- Operation maintenance 100000 h
- Product type
LED driver
- Dim
(L x W x H) 260 x 68 x 47 mm
- Output voltage (max.)
48 V
- Operating voltage
230 V
IP67
- Connection
Braid
- Max. power
350 W
- Input voltage (max.)
240 V
- Min. input voltage
120 V
- Power range
350 W (max)
- Width
68 mm
- Height
47 mm
- Length
260 mm
- Max. temperature
+40 °C
- Min. temperature
-20 °C
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3435813 Self Electronics SLT350-48VLC-UN LED driver 350 W 48 V 1 pc(s)
Description
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
