Self Electronics SLT75-24VL-E LED driver Constant voltage 75 W 3.1 A 24 V DC Suitable for flammable surfaces, Approved f
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
SLT75-24VL-E
- Constant voltage
- 24 V DC
- 3.1 A
Technical specifications
- Product type
LED driver
- Type
Constant voltage
- Dim
(L x W x H) 185 x 60 x 31 mm
- Factory colour
White
Blue
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Test mark
MM, SELV, CCC
- Max. output current
3.1 A
- Output current (max.) - rounded
3.1 A
- Operating voltage
230 V AC
- Protection class
II
- LED driver features
Suitable for flammable surfaces
Approved for use on furniture
adjustable
not dimmable
Surge protection
Overvoltage
IP20
- Connection
Screw terminal
- Max. power
75 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
264 V AC
- Min. input voltage
198 V AC
- Inputs
1
- Weight
310 g
- Power range
75 W (max)
- Type
Pulsed
- Width
60 mm
- Height
31 mm
- Length
185 mm
- Max. temperature
+50 °C
- Min. temperature
-20 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1842703 Self Electronics SLT75-24VL-E LED driver Constant voltage 75 W 3.1 A 24 V DC Suitable for flammable surfaces, Approved f
User & Safety Instructions
User & Safety Instructions 1842703 Self Electronics SLT75-24VL-E LED driver Constant voltage 75 W 3.1 A 24 V DC Suitable for flammable surfaces, Approved f
Warranty Terms
Warranty Terms 1842703 Self Electronics SLT75-24VL-E LED driver Constant voltage 75 W 3.1 A 24 V DC Suitable for flammable surfaces, Approved f
Description
Features
- Independant operating device
- Protection class II, SELV output
- Constant voltage
- IP20
- Protected against overload, short circuit, overvoltage and temperature protection
- EN61347-1, EN61347-2-13, EN55015, EN61000-3-2 etc.
- For LED applications
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
