Senseca DX 330-00 Air probe Calibrated to (DAkkS standards) -20 up to +80 °C 0 up to 100 RH
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
DAkkS DX 330 digital air quality sensor IAQ (e.g. for PRO D5x)
- -20 up to +80 °C
Technical specifications
- Product type
Air probe
- Temperature reading range (min.)
-20 °C
- Temperature reading range (max.)
+80 °C
- Dim
(Ø) 14 mm
- Probe length
172 mm
DAkkS standards
- Weight
95 g
- Humidity reading range (max.)
100 RH
- Humidity reading range (min.)
0 RH
- Temperature reading range
-20 up to +80 °C
- Temperature accuracy
0.1 °C
- Reading category
Ohne Messkategorie
- (Ø)
14 mm
Documents & Downloads
Datasheet
Datasheet 3220221 Senseca DX 330-00 Air probe Calibrated to (DAkkS standards) -20 up to +80 °C 0 up to 100 RH
User & Safety Instructions
User & Safety Instructions 3220221 Senseca DX 330-00 Air probe Calibrated to (DAkkS standards) -20 up to +80 °C 0 up to 100 RH
Description
DX 330 digital air quality sensor (IAQ) for the PRO D01 / PRO D05 hand-held instruments.
The sensor measures:
- temperature
- relative air humidity
- Atmospheric pressure
- CO2
- VOC index
The sensor is factory calibrated and is immediately ready for use. The calibration data is stored in the sensor so that it can be exchanged without recalibration. Equipped with 4-pin M12 plug.
This text is machine translated.
The sensor measures:
- temperature
- relative air humidity
- Atmospheric pressure
- CO2
- VOC index
The sensor is factory calibrated and is immediately ready for use. The calibration data is stored in the sensor so that it can be exchanged without recalibration. Equipped with 4-pin M12 plug.
This text is machine translated.
Features
- Changeable
- Low energy consumption
- quick and precise
- Contains high-quality CO2 and VOC index sensors
- High-quality sensor combination for a detailed assessment of the air quality
