Name: Senseca Pressure transducer 1 pc(s) Precont PU4SK -1 bar up to 600 bar M12 plug (4-pin, A coded) (Ø x L) 27 mm x 110 mm
Brand: Senseca
SKU: 3804413
Availability: InStock

Three metal pressure sensors/valves shown side by side, one bare and two with black right-angle electrical connectors.

Collage of sensor equipment and company tiles: portable measuring devices, environmental monitoring and process automation, plus '7 locations', '60 years' and 'own calibration laboratories'.

Senseca Pressure transducer 1 pc(s) Precont PU4SK -1 bar up to 600 bar M12 plug (4-pin, A coded) (Ø x L) 27 mm x 110 mm-2

1/3

Product type

Pressure transducer

Connector

M12 plug (4-pin, A coded)

Pressure reading range (max.)

600 bar

Max. operating voltage

35 V DC

Type

Precont PU4SK

Datasheet (PDF)

Fast track dispatch on Tue 20 Oct

4 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 325.00 / piece)

€ 325.00

incl. VAT

Only 4 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Universal pressure transmitter for precise pressure measurement in industrial applications

Precise measurement of absolute and relative pressure up to 16 bar
Robust ceramic measuring cell for maximum long-term stability
Flexible communication with FSK, IO-Link or Modbus® RTU

Technical specifications

Ceramic capacitive/ thin-film measuring cell
Housing material: 1.4404 stainless steel (316L)
Protection class III
Temperature-shock and vibration-proof

Product type: Pressure transducer

Type: Precont PU4SK

Connector: M12 plug (4-pin, A coded)

Response time: 5 ms

Outputs: Analogue

Output signal (min.): 2.8 mA

Output signal (max.): 20.5 mA

Resolution: 16 Bit

Accuracy: 0.5 %

Pressure reading range (min.): -1 bar

Pressure reading range (max.): 600 bar

Pressure reading range: -1 bar up to 600 bar

Min. operating voltage: 9 V DC

Max. operating voltage: 35 V DC

Operating voltage: 9 - 35 V DC

Operating current: 22 mA

: IP67/IP69K

Min. temperature: -40 °C

Max. temperature: 100 °C

Length: 110 mm

(Ø): 27 mm

Dim: (Ø x L) 27 mm x 110 mm

Weight: 350 g

Content: 1 pc(s)

Nominal voltage: 24 V DC

Documents & Downloads

Datasheet

Datasheet 3804413 Senseca Pressure transducer 1 pc(s) Precont PU4SK -1 bar up to 600 bar M12 plug (4-pin, A coded) (Ø x L) 27 mm x 110 mm

User & Safety Instructions

User & Safety Instructions 3804413 Senseca Pressure transducer 1 pc(s) Precont PU4SK -1 bar up to 600 bar M12 plug (4-pin, A coded) (Ø x L) 27 mm x 110 mm

Conformity certificate

Conformity certificate 3804413 Senseca Pressure transducer 1 pc(s) Precont PU4SK -1 bar up to 600 bar M12 plug (4-pin, A coded) (Ø x L) 27 mm x 110 mm

Description

The PRECONT® PU4SK is a powerful pressure transmitter for continuous monitoring, control and measurement of absolute and relative pressure in gases, vapors, liquids and dusts. The robust ceramic measuring cell provides precise and long-term stable measurement results – even under demanding process conditions. Thanks to numerous process connections, front-flush membrane as well as FSK, IO-Link and Modbus®-RTU, the sensor can be flexibly integrated in a wide range of applications.

This text is machine translated.

Features

Ceramic measuring cell for measuring ranges up to 16 bar with an accuracy of up to ±0.5 % FSO
Versions with FSK, IO-Link or RS485 Modbus® RTU as well as numerous process connections
Robust stainless steel housing and protection class IP69K/IP67

Scope of delivery

Device
User manual

Description

Features

Ceramic measuring cell for measuring ranges up to 16 bar with an accuracy of up to ±0.5 % FSO
Versions with FSK, IO-Link or RS485 Modbus® RTU as well as numerous process connections
Robust stainless steel housing and protection class IP69K/IP67
