Shelly Shelly Qubino Wave 1 Actuator Z-Wave, Z-Wave+
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 26.04
3
4% = € 1.01
€ 25.03
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 26.04 / piece)
€ 26.04
plus VAT.
Only 10 Piece(s) available
Highlights & Details
Shelly Wave 1 UP relay max 16 A, 1 channel, Z-Wave
- Z-Wave powered
- Create Smart Schedules
- Intelligent scenes
Technical specifications
- Max. Switching voltage AC 240 V
- Max. Switching current AC 16 A
- Max. Switching voltage DC 30 V
- Max. Switching current DC 10 A
- Product type
Actuator
Alexa
Google Home
- Transfer Standard (Smart Home)
Z-Wave
Z-Wave+
- Used at
Indoors
- Power supply (LOV)
mains-powered
- Operating voltage
230 V
- Data transfer (Smart Home)
Wireless
- Channels
1
- Frequency
868.4 MHz
- Mounting type
Flush mount
- Factory colour
Blue
- Width
42 mm
- Height
37 mm
- Depth
16 mm
- Weight
26 g
n.rel.
- Dim
(W x H x D) 42 x 37 x 16 mm
- Hub
Not required
Documents & Downloads
Datasheet
Datasheet 2924221 Shelly Shelly Qubino Wave 1 Actuator Z-Wave, Z-Wave+
User & Safety Instructions
User & Safety Instructions 2924221 Shelly Shelly Qubino Wave 1 Actuator Z-Wave, Z-Wave+
Description
Z-Wave™ Smart switch, 1 channel 16 A
Control a wide range of devices and office equipment such as electric locks, gates, garage doors, irrigation systems, LED strips, Lights and sockets from everywhere. The output contact is voltage-free (dry contact), so that you can connect different power supplies of up to 16 A to the device.
This text is machine translated.
Features
- Dry contact
- Extremely low device consumption: 0.3 W
- Latest technology: Z-Wave 800 series
- 868.4 MHz Z wave frequency band (CEPT countries)
- Automatic setup with SmartStart
- 2-factor authentication for the highest security level
- Supports wireless firmware updates (OTA)
- Compatible with Z-Wave certified gateways and over 4,000 Z-Wave devices.
System requirements
- Z-Wave enabled gateway
