A double-row pin header connector with three black shorting bridges above it, on a white background.

Technical drawing of two cross-sections of a component with dimensions in inches. The left side shows a stepped form, the right side a rectangular form.

1/4

Fischer Elektronik

Our service for you

Datasheet (PDF)

Deutsch (Deutschland)

Fast track dispatch on Wed, 16 Sep

377 Piece(s) (Only while stocks last)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Minimum order quantity: 5

Total (€ 0.23 / piece)

€ 1.15

plus VAT.

Report legal concerns

Highlights & Details

Coding bridge CAB...

Technical specifications

Features: closed
+ strap handle

Pins: 2

CS: 1.27 mm

Content: 1 pc(s)

Dim: (L x W x H) 1.25 x 5.5 x 2.5 mm

Factory colour: Black

Height: 2.5 mm

Length: 1.25 mm

Width: 5.5 mm

Contact surface: Gold plated

Manufacturer part #: CAB 15 G S

Type: CAB 15 G S

Nominal current: 1 A

Nominal voltage: 100 V AC

Pins per row: 2

Insulation material: PA 66

Contact material: Copper alloy

RoHS-compliant: Yes

Product type: Shorting jumper
