SHURflo 8000-443-136 Low voltage impeller pump 6 l/min 12 V
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Pump SHURflo standard 8000-443-136
- 12VDC
- delivery height 30m
- Flow rate: 6 l /
Technical specifications
- Operating voltage
12 V
- Max. delivery head
30 m
- Max. discharge pressure
3 bar
- Max. feed rate
6 l/min
- Product type
Low voltage impeller pump
Documents & Downloads
Datasheet
Datasheet 2873027 SHURflo 8000-443-136 Low voltage impeller pump 6 l/min 12 V
User & Safety Instructions
User & Safety Instructions 2873027 SHURflo 8000-443-136 Low voltage impeller pump 6 l/min 12 V
User & Safety Instructions 2873027 SHURflo 8000-443-136 Low voltage impeller pump 6 l/min 12 V
User & Safety Instructions 2873027 SHURflo 8000-443-136 Low voltage impeller pump 6 l/min 12 V
User & Safety Instructions 2873027 SHURflo 8000-443-136 Low voltage impeller pump 6 l/min 12 V
Conformity certificate
Conformity certificate 2873027 SHURflo 8000-443-136 Low voltage impeller pump 6 l/min 12 V
Description
Pump ShurflStandard 8000-443-136: 6 l/min, 4.1 bar, 1/2 MSPT is a membrane pump with 12V motor for various applications. All 8000 series displacement pumps are self-priming and run dry without damage. This pump is designed for 12 VDC operation and can be equipped with the compact twist-on sieve for additional reliability. The unique design of the pump enables easy maintenance, unsurpassed reliability and fault-free performance.
This text is machine translated.
This text is machine translated.
Features
- 4 bar
- 1/2 MSPT
