Shuttle All-in-one PC, Barebone XPC AIO P55U 7305 39.6 cm (15.6 inch) Full HD Intel® Celeron® 7305 Intel UHD graphics P5
EAN:
Part number:
Item no:
Highlights & Details
Shuttle XPC AIO P55U 7305 39.6 cm (15.6 inch) All-in-one PC, Barebone
- Display: 39.6 cm (15.6 inch) IPS Full HD 1920 x 1080 Pixel
- Intel® Celeron® 7305
- SO-DIMM
- Intel UHD graphics
- w/o OS
Technical specifications
- SSD form factor M.2
- Graphics card family: Intel
- Built-in graphics card model: Intel® UHD Graphics
- WLAN standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)
- HDMI version: 2.0b
- Product type: All-in-one PC Barebone
- Motherboard Intel SoC
- LGA 1700 processor socket
- Product type
All-in-one PC
- Display (cm)
39.6 cm
- Screen size diagonal (inches)
15.6 inch
- Display properties
IPS
- Display resolution
1920 x 1080 Pixel
- Display resolution mode
Full HD
- CPU series
Intel® Celeron®
- CPU
Intel® Celeron® 7305
- Processor/type
7305
- Processor cores (No.)
5 x
- CPU cache
8 MB
- RAM type
SO-DIMM
- RAM / Max. upgrade
64 GB
- Onboard graphics card
Yes
- Onboard graphics card (GPU manufacturer)
Intel
- Onboard graphics card (version)
UHD graphics
- HDD capacity (total)
0 GB
- Hard drive
0 GB
- Drive
w/o hard drive
- Bluetooth
4.2
- Keyboard layout
Keyboard not included
- No. of HDMI ports
1 x
- No. of USB type A 3.1 / 3.2 1st Gen
4 x
- No of. USB type A 3.1 /3.2 2nd gen
2 x
- No. of VGA ports
1 x
- Interfaces
Gigabit LAN (1 Gbps)
USB A (USB 3.1 1st gen)
USB A (USB 3.1 2nd gen)
HDMI™
VGA
- Factory colour
Black
- Width
393.6 mm
- Height
272.5 mm
- Depth
39.8 mm
- Weight
3.25 kg
- PSU power
90 W
- Operating system (Version)
w/o OS
- Display size
- 23 inch
- Display
39.6 cm (15.6 inch)
- Bluetooth
Yes
- Image format
16:9
- Touchscreen (display)
Yes
- Cooling
Passive
- Operating voltage
230 V
- 10/100/1000 Mbps ports
1 x
- Supported monitors
3
- Audio power (max.)
2 W
- Brightness
250 cd/m²
- Type
External AC adapter
- Power supply (details)
100 - 240 V
100 x 100 mm
- Wi-Fi
Yes
- UKCA
not relevant
- Number of speakers
2
- Operating temperature (T-T)
0 - 40 °C
- AC adapter included
yes
- Ethernet LAN
yes
- Cable lock slot
yes
- ECC
no
- VESA mounting
yes
- Number of memory slots
2
- Number of M.2 (M) slots
2
- Headphone outputs
1
- Microphone in
yes
- DC-in jack
yes
- Built-in speaker(s)
yes
- NVMe
yes
- COM ports quantity
2
- Non-ECC
yes
- Trusted Platform Module (TPM)
yes
- Quick start guide
yes
- Power cord included
yes
- Efficient cores
4
- Performance cores
1
- Number of power supply units
1
- Drivers included
yes
- Operating relative humidity (H-H)
10 - 90 %
- Package weight
4.5 kg
- Built-in processor
yes
- Number of processors supported
1
- Built-in camera
yes
- AC adapter output current
4.74 A
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3534202 Shuttle All-in-one PC, Barebone XPC AIO P55U 7305 39.6 cm (15.6 inch) Full HD Intel® Celeron® 7305 Intel UHD graphics P5
Description
The Shuttle XPC all-in-one PCs of the P55U series come with a capacitive 15.6" multi-touch screen in full HD resolution with a Gen12/13 Intel ULV processor. The modern processor architecture has a very positive effect on power consumption and computing power. The existing WLAN-function can be enhanced optionally with a 4G/5G-function with up to 4 antennas. Thanks to passive heat-pipe cooling, the system is practically silent, maintenance-free and suitable for 24/7-continuous operation. Useful for vertical market applications is the placement of most connectors on the bottom of the chassis and the front panel resistance to dust and splash water in accordance with IP54 protection.
This text is machine translated.
This text is machine translated.
