Shuttle Barebone XPC slim 2.5 cm (1 inch) Core Ultra 2xx Desktop-Prozessor 96 GB RAM Intel XB860G2
EAN:
Part number:
Item no:
Shuttle XPC slim 2.5 cm (1 inch) Barebone
Highlights & Details
- Display: 2.5 cm (1 inch)
- Core Ultra 2xx Desktop-Prozessor Arrow Lake
- RAM: 96 GB SO-DIMM
- Intel
- w/o OS
Technical specifications
- Supported memory: DDR5 SDRAM
- SSD form factor M.2
- HDMI version 2.0/2.1
- Panel-mounting interface 75 x 75.100 x 100 mm
- Product type: PC Barebone
- Motherboard form factor: Mini ITX
- Intel B860 motherboard chipset
- LGA 1851 (socket V1)
- Product type
Barebone
- Model
XPC slim
- Display (cm)
2.5 cm
- Screen size diagonal (inches)
1 inch
- CPU
Core Ultra 2xx Desktop-Prozessor
- Processor/type
Core Ultra 2xx Desktop-Prozessor
- Processor generation
Arrow Lake
96 GB
- RAM type
SO-DIMM
- No. of memory slots
2
- RAM / Max. upgrade
96 GB
- Onboard graphics card
Yes
- Onboard graphics card (GPU manufacturer)
Intel
- Dedicated graphics card
No
- SSD connection
M.2 PCIe
- HDD capacity (total)
0 GB
- HDD 1 connection
M.2 PCIe
- Hard drive
0 GB
- HDD 1 type
Flash M.2
- Keyboard layout
Keyboard not included
- No. of DisplayPort
1 x
- No. of HDMI ports
2 x
- No. of USB A 2.0 ports
2 x
- No. of USB type A 3.1 / 3.2 1st Gen
3 x
- No of. USB type A 3.1 /3.2 2nd gen
2 x
- Interfaces
HDMI® 2.0b
- Factory colour
Black
- Width
238 mm
- Height
72.5 mm
- Depth
200 mm
- Weight
1.9 kg
- PSU power
180 W
- Features
w/o CPU
w/o HDD
w/o RAM
- Operating system (Version)
w/o OS
- Display size
- 23 inch
- Display
2.5 cm (1 inch)
- Cooling
Active
- Wireless charging
Yes
- Operating voltage
1.1 V
- 10/100/1000 Mbps ports
2 x
- Type
External AC adapter
- Power supply (details)
100 - 240 V
- Wi-Fi
No
- UKCA
yes
- Operating temperature (T-T)
0 - 50 °C
- Ethernet LAN
yes
- Cable lock slot
yes
- Storage drives installed
no
- VESA mounting
yes
- Number of memory slots
2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
- Headphone outputs
1
- Microphone in
yes
- DC-in jack
yes
- Built-in speaker(s)
no
- NVMe
yes
- Non-ECC
yes
- Trusted Platform Module (TPM)
yes
- Quick start guide
yes
- Power cord included
yes
no
- Number of power supply units
1
- Drivers included
yes
- Operating relative humidity (H-H)
10 - 90 %
- Package weight
3.2 kg
- Built-in processor
no
- Number of processors supported
1
- AC adapter output current
9.23 A
- Number of storage drives supported
3
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3737012 Shuttle Barebone XPC slim 2.5 cm (1 inch) Core Ultra 2xx Desktop-Prozessor 96 GB RAM Intel XB860G2
Description
The Shuttle XPC slim Barebone XB860G2 is a 4.5 liter PC with two slots for PCI express plug-in cards. Together with a powerful LGA1851 Intel core ultra 2xx desktop processor (codename "Arrow Lake-S"), this platform is perfectly suitable, where performance, flexibility and compact design are required. For example, a multi-port graphics card, a video capture card or I/O card can be installed to have a mini PC for video wall presentation, a graphics workstation, audio/video recording, monitoring, POS system, POI and various network and industrial applications to be attached. Even gaming is possible.
