Shuttle Barebone XPC slim DL40N 2.5 cm (1 inch) 4K Intel® N N150 3.6 GHz Intel Not available DL40N
EAN:
Part number:
Item no:
Shuttle XPC slim DL40N 2.5 cm (1 inch) Barebone
Highlights & Details
- Display: 2.5 cm (1 inch) 4K 4096 x 2160 Pixel
- Intel® N N150 4 core(s) / max. 3.6 GHz
- SO-DIMM
- Intel Not available
- w/o OS
Technical specifications
- Installed internal memory: No.
- Graphics card family: Intel
- Built-in graphics card model: Intel graphics
- HDMI version: 2.0b
- Product type: Mini PC Barebone
- Installed operating system: No.
- Sustainability Compliance: Yes
- Product type
Barebone
- Model
XPC slim DL40N
- based on the following CTO model
DL30N
- Display (cm)
2.5 cm
- Screen size diagonal (inches)
1 inch
- Display resolution
4096 x 2160 Pixel
- Display resolution mode
4K
- CPU series
Intel® N
- CPU
Intel® N N150
- Processor/type
N150
- Processor cores (No.)
4 x
- CPU speed
3.6 GHz
- CPU turbo clock speed (max.)
3.6 GHz
- CPU cache
6 MB
- RAM type
SO-DIMM
- No. of memory slots
1
- RAM / Max. upgrade
16 GB
- Onboard graphics card
Yes
- Onboard graphics card (GPU manufacturer)
Intel
- Dedicated graphics card
No
- Onboard graphics card (version)
Not available
- SSD connection
M.2 PCIe
- HDD capacity (total)
0 GB
- Hard drive
0 GB
- Drive
w/o hard drive
- Mobile internet
LTE/4G
- Keyboard layout
Keyboard not included
- No. of DisplayPort
1 x
- No. of Gigabit LANs
2 x
- No. of HDMI ports
1 x
- No. of serial ports
2 x
- No. of USB type A 3.1 / 3.2 1st Gen
8 x
- No. of VGA ports
1 x
- Interfaces
Gigabit LAN (1/2.5 Gbps)
- Factory colour
Black
- Width
165 mm
- Height
43 mm
- Depth
190 mm
- Weight
800 g
- PSU power
65 W
- Features
w/o HDD
w/o RAM
- Operating system (Version)
w/o OS
- Display size
- 23 inch
- Display
2.5 cm (1 inch)
- Cooling
Passive
- Material (details)
Steel
- Power consumption (max.)
6 W
- Operating voltage
1.1 V
- 10/100/1000 Mbps ports
2 x
- Supported monitors
3
- Type
External AC adapter
- Power supply (details)
100 - 240 V
100 x 75 mm
- Wi-Fi
No
- UKCA
yes
- Operating temperature (T-T)
0 - 40 °C
- AC adapter included
yes
- Serial ports quantity
2
- Ethernet LAN
yes
- Cable lock slot
yes
- Storage drives installed
no
- ECC
no
- VESA mounting
yes
- Number of memory slots
1
- ECC supported by processor
no
- Headphone outputs
1
- Microphone in
yes
- DC-in jack
yes
- Built-in speaker(s)
no
- NVMe
yes
- Card reader integrated
no
- Non-ECC
yes
- Trusted Platform Module (TPM)
yes
- Quick start guide
yes
- Power cord included
yes
- Number of power supply units
1
- Drivers included
yes
- On/off switch
yes
- Operating relative humidity (H-H)
10 - 90 %
- Package weight
2.1 kg
- Built-in processor
yes
- Number of processors supported
1
- AC adapter output current
3.42 A
- Number of storage drives supported
2
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3728718 Shuttle Barebone XPC slim DL40N 2.5 cm (1 inch) 4K Intel® N N150 3.6 GHz Intel Not available DL40N
Description
Quiet and powerful. The Shuttle XPC slim Barebone DL40N is the successor to the proven DL30N and is designed for environments where reliability and low noise are indispensable. Powered by the energy-efficient Intel "Twin Lake-N" N150 processor, this fanless 1.35-liter PC is the ideal foundation for lean workstations, robust edge computing or highly available client/server configurations.
Connectivity is at the heart of the DL40N. With two Intel 2.5G LAN ports for high-speed networks and an optional 4G upgrade, it ensures seamless integration even in mobile or remote applications. Built-in Intel UHD graphics card supports hardware acceleration for playback of 4K video on three independent screens (HDMI, DisplayPort, VGA), making it a versatile choice for digital signage and multi-screen office environments.
The DL40N is designed for continuous operation around the clock and is housed in a robust metal case. It works silently in combination with an SSD. Whether for industrial control, the Point-of-sale or for use in quiet office environments - the DL40N offers professional performance in a compact, maintenance-free form factor.
This text is machine translated.
Connectivity is at the heart of the DL40N. With two Intel 2.5G LAN ports for high-speed networks and an optional 4G upgrade, it ensures seamless integration even in mobile or remote applications. Built-in Intel UHD graphics card supports hardware acceleration for playback of 4K video on three independent screens (HDMI, DisplayPort, VGA), making it a versatile choice for digital signage and multi-screen office environments.
The DL40N is designed for continuous operation around the clock and is housed in a robust metal case. It works silently in combination with an SSD. Whether for industrial control, the Point-of-sale or for use in quiet office environments - the DL40N offers professional performance in a compact, maintenance-free form factor.
This text is machine translated.
