Surge protection 3RT29261CD00 + RC circuit Black 1 pc(s) Siemens 3RT2926-1CD00
EAN:
Part number:
Item no:
Product type
Surge protection
Content
1 pc(s)
Features
+ RC circuit
Factory colour
Black
Mounting type
Push-fit
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 21.00
3
4% = € 0.92
€ 20.08
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 21.00 / piece)
€ 21.00
plus VAT.
Only 3 Piece(s) available
Technical specifications
- Voltage type AC/DC
- Size of contactor: S0
- Control supply voltage frequency 60 Hz
- Product type
Surge protection
- Content
1 pc(s)
- Features
+ RC circuit
- Factory colour
Black
- Mounting type
Push-fit
- Min. operating voltage
127 V AC
150 V DC
- Max. operating voltage
240 V AC
250 V DC
- Operating voltage
127, 150 - 240, 250 V AC, V DC
- Compatible with
Siemens
- Compatible with series
Siemens Sirius series
- Min. temperature
-25 °C
- Max. temperature
+60 °C
- Width
30 mm
- Height
19 mm
- Length
12 mm
- Dim
(L x W x H) 12 x 30 x 19 mm
- RoHS-compliant
Yes
- Type
3RT2926-1CD00
- Type
3RT 2926-1 CD00
AC/DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1430979 Surge protection 3RT29261CD00 + RC circuit Black 1 pc(s) Siemens 3RT2926-1CD00
Datasheet 1430979 Surge protection 3RT29261CD00 + RC circuit Black 1 pc(s) Siemens 3RT2926-1CD00
User & Safety Instructions
User & Safety Instructions 1430979 Surge protection 3RT29261CD00 + RC circuit Black 1 pc(s) Siemens 3RT2926-1CD00
Description
Surge suppressor, RC element, AC 127...240V, DC 150 ... 250V, for motor contactors size S0, thanks to the mounting axis already in the contactor, the surge suppressor can be inserted very easily and without any effect on the external dimensions.
