Siemens 3SE51120LD021AA7 3SE5112-0LD02-1AA7 Door-operated switch Tappet 1 pc(s)

Position switches Metal housing 40 mm according to DIN EN 50041 Roller plunger with 13 mm stainless steel roll with 3 mm overstroke, 1S/2Ö jump contacts, device connection 1x (M20 x 1.5), actuation/reset force 30N available only as a complete device Mechanical position switches SIRIUS 3SE5 for position and position detection of machine components and position monitoring of protective devices.
The modular design of the 3SE5 position switches enables a variety of variants with a small number of bearing types. The wide variety of plug and rollers meets almost all requirements in industrial everyday life. LEDs indicate the current status of the device. Thanks to quick connection technology, connection times can be reduced considerably. Switching points and fixing to EN 50047 and EN 50041. The devices are approved worldwide (IEC, UL). The highest security requirements can be established according to PL e or SIL 3 must be satisfied. The integrated ASIsafe electronics require low power consumption.
There are various housing sizes available, with different switching elements, in plastic or metal or compact design. Some versions are available with optional LED status indicator and M12 connector. The 3SF1 series with direct connection to the AS-Interface bus system rounds off the portfolio.
Depending on the version, drive heads and plugs as well as additional mounting/connection accessories are available.
Safety is a SIRIUS business.

This text is machine translated.
