Buy Siemens 3SU10003BB420AA0 3SU1000-3BB42-0AA0 Double head pushbutton momentary (W x H) 29.9 mm x 57.9 mm IP66, IP67, IP69/

'An oval switch with a green upper area and a red lower area, with a transparent strip running between them.'

Image similar

Cable car station with a gondola in the background; in the foreground, a control panel with emergency buttons for operation.

Technical drawing of an oval handle with dimensions: Height 57.9 mm, Width 29.9 mm, Depth 44.2 mm.

1/3

Image similar

Packaging type

Piece

Product type

Double head pushbutton

Lighting type

None

Width

29.9 mm

Recess diameter

22.3 mm

Datasheet (PDF)

Dispatches on Mon, 21 Sep

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 16.80 / piece)

€ 16.80

plus VAT.

Report legal concerns

Technical specifications

Weight: 26 g

Packaging type: Piece

Product type: Double head pushbutton

Switch/button features: round

Casing/button colour: Green
Red

Functions: momentary

Type: Activation/message element

Lighting type: None

Material: Plastic

Contact material: Plastic

Min. temperature: -25 °C

Shape: Oval

Max. temperature: +70 °C

Width: 29.9 mm

Height: 57.9 mm

Recess length: 57.9 mm

Durability: 2000000

Recess diameter: 22.3 mm

Recess depth: 25.5 mm

Recess width: 29.9 mm

Front panel cut-out: 22 mm

: IP66
IP67
IP69/IP69K

Content: 1 pc(s)

Dim: (W x H) 29.9 mm x 57.9 mm

RoHS-compliant: Yes

Type: 3SU1000-3BB42-0AA0

: 22.3 mm

: FALSE

: 1

: FALSE

: FALSE

: Black

: Other

: FALSE

: Plastic

: TRUE

: Oval

: FALSE

: Other

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1699939 Siemens 3SU10003BB420AA0 3SU1000-3BB42-0AA0 Double head pushbutton momentary (W x H) 29.9 mm x 57.9 mm IP66, IP67, IP69/

User & Safety Instructions

User & Safety Instructions 1699939 Siemens 3SU10003BB420AA0 3SU1000-3BB42-0AA0 Double head pushbutton momentary (W x H) 29.9 mm x 57.9 mm IP66, IP67, IP69/

Information

Information 1699939 Siemens 3SU10003BB420AA0 3SU1000-3BB42-0AA0 Double head pushbutton momentary (W x H) 29.9 mm x 57.9 mm IP66, IP67, IP69/

Description

Magnet switch Contact block 25 x 88 mm, for door hinge on the left Contact elements: Safety contacts 2 NC with M8 connector, 4-pole with combi connection Screw/latching connection with LED, the matching solenoid 3SE6714-2CA or offset by 90° 3SE6724-2CA
