Siemens 3TF6944-8CF7 Contactor 3 makers 1 pc(s)
EAN:
Part number:
Item no:
Product type
Contactor
No. of pins
3-pin
Connection
Screws
Type
3TF6944-8CF7
Contact type
3 makers
Datasheet (PDF)
Number
Total (€ 5,046.22 / piece)
€ 5,046.22
plus VAT.
Technical specifications
- Type of voltage: AC
- Size: 14
- Product type
Contactor
- Type
3TF6944-8CF7
- No. of pins
3-pin
- Contact type
3 makers
- Mounting type
Screw-fit
- Connection
Screws
IP00
- Min. temperature
-25 °C
- Max. temperature
+55 °C
- Width
230 mm
- Height
295 mm
- Depth
237 mm
- Dim
(W x H x D) 230 x 295 x 237 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
TRUE
450 kW
3
0
4
4
820 A
910 A
Rail connection
AC
690 A
514.849125
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1752245 Siemens 3TF6944-8CF7 Contactor 3 makers 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1752245 Siemens 3TF6944-8CF7 Contactor 3 makers 1 pc(s)
Description
Contactor, Size 6, 3-pole, AC-3, 55 kW, 400/380 V Auxiliary contacts 22 (2 NO + 2 NC) 24 V DC DC operation ! Phased-out product! Successor is SIRIUS 3RT Preferred successor type is 3RT2047-3NB30
