A black Siemens time-delay relay with multiple terminals and the inscription '7PV3500' on the front, shown from the side.

Image similar

A black Siemens time-delay relay with multiple terminals and the inscription '7PV3500' on the front, shown from the side.

'Circuit diagram of a Siemens SIMOCODE PRO device with connections IN1 to IN4 and OUT1 to OUT2, showing the logic control and status indication.'

Technical drawing of an electrical component with dimensions: Height 94.5 mm, Width 22.5 mm, Length 124 mm.

1/3

Image similar

Siemens

Datasheet (PDF)

Dispatches on Thu, 17 Sep

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 231.09 / piece)

€ 231.09

plus VAT.

Report legal concerns

Technical specifications

Isolation voltage: 300 V
Control supply voltage: 24 V/DC - 24 V/DC
Surge voltage resistance: 4000 V
Electrical life: 100000

Product type: Digital module

Type: 3UF7310-1AB00-0

Manufacturer part #: 3UF73101AB000

Type: Screw connector

No. of digital inputs (max.): 4

No. of inputs (max.): 4

No. of outputs (max.): 2

Height: 92 mm

Length: 124 mm

Width: 22.5 mm

: IP20

Dim: (L x W x H) 124 x 22.5 x 92 mm

Content: 1 pc(s)

Fitting type (details): Screw and snap

Max. ambient temperature: +60 °C

Min. ambient temperature: -25 °C

: Digital module

: Bistable

: 4

: 0

: 0

: 4

: IP20

: 0

: 2

: Screw connection

: FALSE

: FALSE

: FALSE

: DC

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1740725 Siemens 3UF73101AB000 3UF7310-1AB00-0 Digital module

User & Safety Instructions

User & Safety Instructions 1740725 Siemens 3UF73101AB000 3UF7310-1AB00-0 Digital module

Description

Current measuring module, Set current 2.4...25 A Overall width 45 mm, straight-through transformer
