Siemens 3UG4641-1CS20 Single Phase Voltage Monitoring Relay, Digital, N/A
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Monitoring relay
Functions
Power factor monitoring
Active current
Max. operating voltage
690 V AC
Contact type
1 change-over
Datasheet (PDF)
Number
Total (€ 256.30 / piece)
€ 256.30
plus VAT.
Technical specifications
- Switch-on delay: 0 - 99 s
- Measuring range: cos phi) 0.1 - 99, (active power) 0.2 - 10 A
- Packaging type
Piece
- Product type
Monitoring relay
- Type
3UG4641-1CS20
- Functions
Power factor monitoring
Active current
- Min. operating voltage
90 V AC
- Max. operating voltage
690 V AC
- Operating voltage
90 - 690 V AC
- Amperage adjustment range (min.)
0.2 A
- Amperage adjustment range (max.)
10 A
- Adjustment range (amperage)
0.2 - 10 A
- Contact type
1 change-over
- Switching voltage (max.)
690 V AC
- Width
22.5 mm
- Height
110 mm
- Dim
(L x W x H) 86 x 22.5 x 110 mm
- Content
1 pc(s)
- Length
86 mm
- Type
Monitoring relay for Cos phi and active current
- Type
3UG4641-1CS20
- Operating voltage
90 - 690 V AC
22.5
102 mm
91 mm
1
TRUE
Screw connection
99 s
0 s
20 s
0.1 s
AC
0
0
2
Documents & Downloads
Datasheet
Datasheet 502512 Siemens 3UG4641-1CS20 Single Phase Voltage Monitoring Relay, Digital, N/A
Datasheet 502512 Siemens 3UG4641-1CS20 Single Phase Voltage Monitoring Relay, Digital, N/A
User & Safety Instructions
User & Safety Instructions 502512 Siemens 3UG4641-1CS20 Single Phase Voltage Monitoring Relay, Digital, N/A
Description
The SIRIUS monitoring relay 3UG4 provide optimum protection for machinery and equipment, permanently installed to protect against over-or undervoltage, or for the complete network monitoring with portable equipment. Also, monitoring of the load of motors and the functionality of electrical loads is done by monitoring relay 3UG4 for current, cos phi and active current monitoring. The monitoring relay 3UG4 also control non-electrical quantities such as liquid levels or even the speed of motors
Special features: Due to the Wide span used by all networks in the world, permanent display of value and type of error in digital versions, all versions with removable terminals, small width.
