PV fuse (W x H x D) 105 x 158 x 70 mm Siemens 3VA1220-4EF32-0AA0 1 pc(s)
EAN:
Part number:
Item no:
Product type
PV fuse
Content
1 pc(s)
Dim
(W x H x D) 105 x 158 x 70 mm
RoHS-compliant
Yes
Type
3VA1220-4EF32-0AA0
Datasheet (PDF)
Number
Total (€ 637.82 / piece)
€ 637.82
plus VAT.
14-day return policy included
Technical specifications
- Design: System Protection
- Mechanical life: 15000
- Electrical life: 8000
- Isolation voltage: 800 V
- Mains frequency: 50/60 Hz.
- Power loss: 14 W
- Weight: 1,606 kg
- Product type
PV fuse
- Dim
(W x H x D) 105 x 158 x 70 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
3VA1220-4EF32-0AA0
- Depth
70 mm
- Height
158 mm
- Width
105 mm
IP40
- Connection
Screws
- Breaking capacity rating
S
- OCR type
TM240
- Mounting type
Fixed
- No. of pins
3-pin
- Amperage adjustment range (max.)
200 A
- Amperage adjustment range (min.)
140 A
- Switching voltage (max.)
690 V AC
- Max. temperature
+70 °C
- Min. temperature
-25 °C
0
0
200 A
3
140-200 A
0
690-690 V
42 W
IP40
Front side
FALSE
Screw connection
Rocker lever
36 kA
TRUE
FALSE
TRUE
Built-in device fixed built-in technique
TRUE
TRUE
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1538988 PV fuse (W x H x D) 105 x 158 x 70 mm Siemens 3VA1220-4EF32-0AA0 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1538988 PV fuse (W x H x D) 105 x 158 x 70 mm Siemens 3VA1220-4EF32-0AA0 1 pc(s)
Description
Circuit breaker 3VA1 IEC Frame 250 switching capacity class S ICU=36kA @ 415V 3-pin, system protection TM240, ATAM, in=200A Overload protection IR=140A...200A Short-circuit protection II=5...10 x in screw-flat connection Compact circuit breaker 3VA1 for starter protection. The 3VA compact circuit breakers from Siemens are an important component of the SENTRON protective components for industrial applications as well as for applications in the infrastructure sector and offer effective plant, starter and motor protection through safe shutdown in the event of an overload or short-circuit. The 3VA compact circuit breakers set new standards in flexibility and a wide range of modular accessories. Uniform accessories for several sizes across all series of 3VA1 and 3VA2 compact circuit breakers. This version of the 3VA compact circuit breaker is characterized above all by: 1. Compact design. 2. Available as a starter protection variant for protecting electric motors against short-circuits. 3. Available in 3-pin design. 4. Depending on the size: Rated operating current of 32 A....200 A. 5. Switching capacity of 55 kA ... 70 kA at 415 V. 6. Mounting in fixed installation and plug-in technology possible. 7. The series has a thermal-magnetic overcurrent release 8. Modular and easy to install internal accessories with a wide range of functions. 9. Integrated accessory platform via all 3VA compact circuit breakers. Siemens offers a comprehensive portfolio of protection, switching, measuring and monitoring devices, distribution systems, switches and sockets for the safe, efficient electrical infrastructure in buildings and industry.
