Siemens 5SU13546LB20 RCBO 20 A
EAN:
Part number:
Item no:
Product type
RCBO
Number of pins
2
Release characteristics
B
Nominal current - rounded value
20 A
Switch-off capacity
10 kA
Datasheet (PDF)
Technical specifications
- Number of width-division units: 2
- Number of test cycles / for environmental testing: 28
- Tightening torque / with screw connection / minimum: 2.5 Nm
- Tightening torque / for screw connection / maximum: 3 Nm
- Design of the basic type: 5SU1
- All mounting positions permitted
- Mounting depth: 70 mm
- Mechanical life (cycles) / typical: 10000
- Number of pins / note: 1P+N
- Number of poles / with security: 1
- Location / power cable: Either top or bottom
- Product features / protection against contact: Yes
- Product property / halogen-free: Yes
- Product property / lead-sealable: Yes
- Product property / silicone-free: Yes
- Product function / switching neutral conductor: Yes
- Switching capacity (ICU+) 25 kA
- Switching capacity Current / according to EN 60898: 10 kA
- Switching capacity Current / according to IEC 60947-2: 20 kA
- Protection class IP: IP20, in distributor installation, with connected conductors
- Ambient temperature / during operation / minimum: -25 °C.
- Ambient temperature / during operation / maximum: +55 °C
- Power loss / at rated current / at AC / at warm operating state / per pole: 3.7 W.
- Power loss/maximum 7.4 W.
- Pollution level: 2
- Supply voltage frequency 50 Hz
- Operating frequency / Note: 50/60 Hz
- Over voltage category III
- Switch-off characteristic: Short-time delay G, super-resistant K
- Breaking current 30 mA
- Suitability for integration / flush mounting: Yes
- Insulation voltage 264 V
- Protection function/false triggering: Yes
- Supply voltage / for test equipment / minimum: 195 V.
- Cross-section/single-wire: 0.75 mm² - 35 mm²
- Cross-section/fine wire/wire-end processing: 0.75 mm² - 25 mm²
- Cross-section/multi-wire connection: 0.75 mm² - 35 mm²
- Type
Short-time delay G, super-resistant K
- Nominal voltage (details)
230/240 V AC
- Product type
RCBO
- Number of pins
2
- Operating class
3
- Release characteristics
B
- RoHS-compliant
Yes
- Dim
(W x H x D) 36 x 90 x 77 mm
- Content
1 pc(s)
- Nominal current
20 A
- Nominal current - rounded value
20 A
- Switch-off capacity
10 kA
- Width
36 mm
- Height
90 mm
- Depth
77 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2865070 Siemens 5SU13546LB20 RCBO 20 A
User & Safety Instructions
User & Safety Instructions 2865070 Siemens 5SU13546LB20 RCBO 20 A
Description
FI/LS switch, 10 kA, 1P+N, type A, short-term delay G, Super-resistant K 30 mA, B-Char, In: 20 A, Un AC: 230 V FI/LS-switch SENTRON 5SU1 for the combined protection against overload, short circuit and fault currents
Our FI/LS-switches (RCBO) are VDE-tested and certified according to DIN EN 61009-1, DIN EN 61009-2-1. With its double chamber clamps the connection of conductors of different cross-sections is also very simple. Further Siemens SENTRON circuit breakers can be quickly and easily connected with the 5 ST3 pin busbars. The data matrix code on the device gives you quick access to all technical data in the Siemens Industry Online Support APP.
