Siemens 5SV36466 5SV3646-6 RCCB A 4-pin 63 A 0.3 A 400 V
EAN:
Part number:
Item no:
Product type
RCCB
Number of pins
4
Release characteristics
A
Differential current rating
0.3 A
Nominal current - rounded value
63 A
Datasheet (PDF)
Number
Total (€ 80.66 / piece)
€ 80.66
plus VAT.
Technical specifications
- Mechanical life (Cycles): 10000
- IP20, for distributor installation, with the connected conductors
- Product type
RCCB
- Number of pins
4
- Release characteristics
A
- Differential current rating
0.3 A
- Nominal current
63 A
- Nominal current - rounded value
63 A
- Dim
(L x W x H) 70 x 72 x 90 mm
- Type
Design of the product: without delay; Mounting Type: DIN rail
- Switch-off capacity
0.8 kA
- Factory colour
Grey
- Content
1 pc(s)
- Nominal voltage
400 V
- Width
72 mm
- Height
90 mm
- Length
70 mm
- Depth
70 mm
- Weight
0
AC
70 mm
63 A
400 V
4
0.3 A
4
FALSE
0.75-35 mm²
0.75-35 mm²
-25-45 °C
TRUE
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1418953 Siemens 5SV36466 5SV3646-6 RCCB A 4-pin 63 A 0.3 A 400 V
User & Safety Instructions
User & Safety Instructions 1418953 Siemens 5SV36466 5SV3646-6 RCCB A 4-pin 63 A 0.3 A 400 V
Description
FI-protection switch Type A63 A3 + N-pole. 300 mA 400 V 4 TE
