Siemens 6ED1055-5MC08-0BA3 Communication module

CIM Communication Interface Module for LOGO! 8 ModbusRTU Interface (RS232/485) 4-port switch, without 4G/LTE/GPS engine, without antennas, web configurator The communication module LOGO! CIM is an expansion module for the LOGO! Logic module 8 and space-saving combines several communication protocols in one device. A 4-port switch is integrated in the casing for the connection of further devices via Ethernet, a Modbus RTU and TCP interface enables the connection of corresponding sensors. Also integrated are a SIM card slot (4G/LTE) and an mPCIe slot for 4G/LTE module engines. This enables communication to the AWS cloud, for example, even if no LAN infrastructure is available. The NTP function and the GPS receiver that can be extended via mPCIe are the prerequisite for time synchronization and the recording of position data. IPV4 and IPV6 addressing are supported when used with the 4G/LTE engine. In order to achieve full functionality, especially in the mobile field, the CIM module can be extended with antennas and a 4G/LTE engine. Tested engines are available for the frequency ranges of different regions, so that the module can be used almost globally. For details on the suggested antennas and LTE engines, refer to the CIM module manual.

This text is machine translated.
