Image similar
Siemens Magnet splitter/globe valve BPZ:M3FB32LX BPZ:M3FB32LX 24 V AC 32 mm Nominal width (details) 32 mm 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Magnet splitter/globe valve
- Operating voltage
24 V AC
- Enclosure material
Steel
- Connection
32 mm
- Media temperature (range)
-40 up to 120 °C
- Manufacturer part #
BPZ:M3FB32LX
- Max. media temperature
120 °C
- Media temperature (min.)
-40 °C
- Nominal width
32 mm
- Height
379 mm
IP54
- Max. ambient temperature
50 °C
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3753744 Siemens Magnet splitter/globe valve BPZ:M3FB32LX BPZ:M3FB32LX 24 V AC 32 mm Nominal width (details) 32 mm 1 pc(s)
Description
Hermetically sealed control valves for continuous power control of refrigeration machines and for heat recovery. - PS43 with CrNi steel solder connections - For organic safety refrigerants such as R22, R134a, R404A, R407C, R410A, R507 etc. Not suitable for flammable refrigerants. - Connection electronics ZM must be ordered separately, see accessories
This text is machine translated.
This text is machine translated.
Hints
The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
