Technical specifications
- Product type
Wire core
- No. of leads
1 x
- Content
100 m
- Cross section (each core)
1.5 mm²
- Insulation material
Silicone
- Cable features
Heat-resistant
- Manufacturer part #
SIF 1x1,5 schwarz
- Sold per metre
Yes
- Cross section
1 x 1.5 mm²
- Max. temperature range (flexible installation)
180 °C
- Min. temperature range (flexible installation)
-50 °C
- Max. temperature range (fixed installation)
180 °C
- Min. temperature range (fixed installation)
-50 °C
- Type
SIF 1x1,5 schwarz
- Standards
Verband Deutscher Elektrotechniker e.V. (VDE)
1.5 mm²
500 V
Class 5 = flexible
Black
300 V
2.8 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2984705 SIF 1x1,5 schwarz Wire core 1 x 1.5 mm² 100 m
Description
Based on VDE 0250 rated voltage: 300 / 500 VConstruction: Conductors made of finely stranded tin-plated copper wire, wire insulation made of silicone rubber, color: Brown.Use: This heat and cold-resistant (-50°C to + 180°C) cables are used everywhere where heat influences (or cold) have direct influence (e.g. wiring of lights, switchgear, foundries, steel / steelworks, glass / ceramic industry, etc.).
