Hirschmann Test & Measurement PRUEF 1 sw Test tip 931376100 Soldering Ohne Messkategorie Black 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.61
5
7% = € 0.30
€ 4.31
10
9% = € 0.42
€ 4.19
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.61 / piece)
€ 5.03
-8 %
€ 4.61
plus VAT.
14-day return policy included
Highlights & Details
Probe tip PRÜF 1 - black
- For SMD technology
Technical specifications
- Product type
Test tip
- Connection
Soldering
- Nominal voltage
30 V AC
60 V DC
- Factory colour
Black
- Reading category
Ohne Messkategorie
- Length
90 mm
- Tip diameter
1 mm
- Tip length
3 mm
- Tip material
Stainless steel, nickel-plated
- Max. resistance
50 mΩ
- Nominal current
1 A
- Nominal current - rounded value
1 A
- Shaft length
51 mm
- Temperature range
-25 °C - +60 °C
Documents & Downloads
Datasheet
Datasheet 138290 Hirschmann Test & Measurement PRUEF 1 sw Test tip 931376100 Soldering Ohne Messkategorie Black 1 pc(s)
User & Safety Instructions
User & Safety Instructions 138290 Hirschmann Test & Measurement PRUEF 1 sw Test tip 931376100 Soldering Ohne Messkategorie Black 1 pc(s)
Description
Mini probe tip for contact with small measurement points. Sturdy grip sleeve, can be removed. Solder connection up to 0.5 mm2 and max. 2 mm cable outside-Ø.
