Spelsberg 22943201 Cable gland shockproof, with strain relief, with locknut M32 Plastic Light grey 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable gland
External thread
M32
Type
straight, untreated
Material
Plastic
Clamp Ø
11 mm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.61
5
7% = € 0.30
€ 4.31
10
9% = € 0.42
€ 4.19
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.61 / piece)
€ 5.87
-21 %
€ 4.61
plus VAT.
14-day return policy included
Technical specifications
- Thread pitch 1.5 mm
- Type of seal: Sealing ring
- Hexagonal corner dimensions 40 mm
- Product type
Cable gland
- Features
shockproof
with strain relief
with locknut
- Factory colour
Light grey
- External thread
M32
- Type
straight, untreated
- Material
Plastic
- Clamp Ø
11 mm
- Terminal Ø (max.)
21 mm
- Thread length
15 mm
- Min. temperature
-25 °C
- Max. temperature
+100 °C
IP68
- Spanner size
36 mm
- Halogen-free
Yes
- Content
1 pc(s)
- Manufacturer part #
22943201
- Type
KVR M32 LG-MGM
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2379511 Spelsberg 22943201 Cable gland shockproof, with strain relief, with locknut M32 Plastic Light grey 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2379511 Spelsberg 22943201 Cable gland shockproof, with strain relief, with locknut M32 Plastic Light grey 1 pc(s)
Description
Cable gland with strain relief, long thread, M_ x 1.5mm, with locknut, polyamide, gray
