Spelsberg 24741201 Cable gland shockproof, with strain relief M12 Plastic Light grey 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable gland
External thread
M12
Type
straight, untreated, glass fiber reinforced
Material
Plastic
Clamp Ø
2 mm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 1.67
10
8% = € 0.13
€ 1.54
25
11% = € 0.18
€ 1.49
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 1.67 / piece)
€ 1.67
plus VAT.
14-day return policy included
Technical specifications
- Thread pitch 1.5 mm
- Type of seal: Sealing ring
- Hexagonal corner dimensions 16.5 mm
- Product type
Cable gland
- Features
shockproof
with strain relief
- Factory colour
Light grey
- External thread
M12
- Type
straight, untreated, glass fiber reinforced
- Material
Plastic
- Clamp Ø
2 mm
- Terminal Ø (max.)
6.5 mm
- Thread length
8 mm
- Min. temperature
-25 °C
- Max. temperature
+100 °C
IP68
- Spanner size
15 mm
- Halogen-free
Yes
- Content
1 pc(s)
- Manufacturer part #
24741201
- Type
KVR M12
Grey
Straight
TRUE
TRUE
7035
Untreated
15 mm
8 mm
TRUE
FALSE
TRUE
Sealing ring
Polyamide (PA)
-25-100 °C
Metric
Plastic
1.5 mm
FALSE
FALSE
FALSE
FALSE
16.5 mm
FALSE
2-6.5 mm
IP68
None
Other
12
None
FALSE
FALSE
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2379514 Spelsberg 24741201 Cable gland shockproof, with strain relief M12 Plastic Light grey 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2379514 Spelsberg 24741201 Cable gland shockproof, with strain relief M12 Plastic Light grey 1 pc(s)
Description
Cable gland, IP68, with strain relief, polyamide, M_ x 1.5mm, Without counter nut
