Spelsberg 24745001 Cable gland shockproof, with strain relief M50 Plastic Light grey 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable gland
External thread
M50
Type
straight, untreated, glass fiber reinforced
Material
Plastic
Clamp Ø
27 mm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 20.16
3
5% = € 1.00
€ 19.16
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 20.16 / piece)
€ 20.16
plus VAT.
14-day return policy included
Technical specifications
- Thread pitch 1.5 mm
- Type of seal: Sealing ring
- Hexagonal corner dimensions 60 mm
- Product type
Cable gland
- Features
shockproof
with strain relief
- Factory colour
Light grey
- External thread
M50
- Type
straight, untreated, glass fiber reinforced
- Material
Plastic
- Clamp Ø
27 mm
- Terminal Ø (max.)
34.5 mm
- Thread length
13 mm
- Min. temperature
-25 °C
- Max. temperature
+100 °C
IP68
- Spanner size
55 mm
- Halogen-free
Yes
- Content
1 pc(s)
- Manufacturer part #
24745001
- Type
KVR M50
Grey
Straight
TRUE
TRUE
7035
Untreated
55 mm
13 mm
TRUE
FALSE
TRUE
Sealing ring
Polyamide (PA)
-25-100 °C
Metric
Plastic
1.5 mm
FALSE
FALSE
FALSE
FALSE
60 mm
FALSE
27-34.5 mm
IP68
None
Other
50
None
FALSE
FALSE
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2379521 Spelsberg 24745001 Cable gland shockproof, with strain relief M50 Plastic Light grey 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2379521 Spelsberg 24745001 Cable gland shockproof, with strain relief M50 Plastic Light grey 1 pc(s)
Description
Cable gland, IP68, with strain relief, polyamide, M_ x 1.5mm, Without counter nut
