Spelsberg 59101301 SVi H 12P-g Feeder box Structure Content 1 pc(s)
EAN:
Part number:
Item no:
Product type
Feeder box
Mounting type
Structure
Width
150 mm
Height
300 mm
Depth
137 mm
Datasheet (PDF)
Number
Total (€ 147.05 / piece)
€ 147.05
plus VAT.
14-day return policy included
Technical specifications
- Protection class: IP54Material: PlasticInstallation depth: 119 mm
- Product type
Feeder box
- with PE and N terminals
Yes
- Mounting type
Structure
- Width
150 mm
- Height
300 mm
- Dim
(W x H x D) 150 x 300 x 137 mm
- Depth
137 mm
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2379391 Spelsberg 59101301 SVi H 12P-g Feeder box Structure Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2379391 Spelsberg 59101301 SVi H 12P-g Feeder box Structure Content 1 pc(s)
Description
Industrial quality power supply box, for 230 V AC networks (L-N-PE / L-PEN) according to VDE-AR-N 4102 (house connection box for single-phase connection), In=25 A, Imax=63 A, equipped with: 1 x NH00 fuse element, 1 x N terminal, 1 x PE-N clamp, 1 x PE-N bridge 10qmm, 1 x parking bay for 2 wiresConnecting terminals lead: Prismatic terminal (2.5-50mm2 CU, 16-50mm2 AL)Terminals Output: Screw connection (2x 2.5-50mm2 CU), gray cover
This text is machine translated.
This text is machine translated.
Hints
Safety relevant component - Only by skilled workers
