Buy Spelsberg GLE 440 Circuit breaker 1 pc(s) Adjustment range (amperage): 280 - 4000 A Switching voltage (max.): 690 V AC (

Electrical control cabinet with a transparent door, main switch visible in the centre. Enclosure with multiple mounting points.

Product type

Circuit breaker

Amperage adjustment range (max.)

4000 A

Type

GLE 440

Amperage adjustment range (min.)

280 A

Adjustment range (amperage)

280 - 4000 A

Datasheet (PDF)

Dispatches on Wed, 7 Oct

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 2,074.79 / piece)

€ 2,074.79

plus VAT.

Report legal concerns

Technical specifications

Product type: Circuit breaker

Type: GLE 440

Amperage adjustment range (min.): 280 A

Amperage adjustment range (max.): 4000 A

Adjustment range (amperage): 280 - 4000 A

Current load: 400 A

No. of pins: 3-pin

Switching voltage (max.): 690 V AC

: IP54

Depth: 254 mm

Width: 320 mm

Height: 640 mm

Dim: (W x H x D) 320 x 640 x 254 mm

Content: 1 pc(s)

: 690 V

: 3

: IP54

: 690 V

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 2379059 Spelsberg GLE 440 Circuit breaker 1 pc(s) Adjustment range (amperage): 280 - 4000 A Switching voltage (max.): 690 V AC (

User & Safety Instructions

User & Safety Instructions 2379059 Spelsberg GLE 440 Circuit breaker 1 pc(s) Adjustment range (amperage): 280 - 4000 A Switching voltage (max.): 690 V AC (

Description

Circuit breaker housing, industrial quality with external actuation, lockable, 1 x circuit breaker, ln 400A, 3-pole switching, LI-trigger, L-trigger thermo-magnetic 0.7-1x in, continuously adjustable (Min/Med/Max), I-trigger magnetic, adjustable 5-10x in, without delay, Rated short-circuit breaking capacity ICU: 36kA(415V), screw connection M10, PE/N terminal M12, 4 x housing connectors (GGV), with transparent cover

This text is machine translated.
