Spelsberg TK PS 1313-7-tm Fitting bracket 130 x 130 x 75 Polycarbonate (PC), Polystyrene (EPS) Grey-white (RAL 7035) 1 p
EAN:
Part number:
Item no:
Product type
Fitting bracket
Material
Polycarbonate (PC)
Polystyrene (EPS)
IP rating
IP66
Width
130 mm
Height
75 mm
Datasheet (PDF)
34 Piece(s)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 20.16
3
5% = € 1.00
€ 19.16
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 20.16 / piece)
€
Highlights & Details
Spelsberg TK PS 1313-7-tm Fitting bracket 130 x 130 x 75 Polycarbonate (PC), Polystyrene (EPS) Grey-white (RAL 7035) 1 pc(s)
- Polycarbonate (cover plate) / polystyrene (lower box)
Technical specifications
- Authorization: Basic materials with UL "Yellow Card"
- Product type
Fitting bracket
- Features
pre-punched
Cover (clear)
- Material
Polycarbonate (PC)
Polystyrene (EPS)
IP66
- Factory colour
Grey-white (RAL 7035)
- Type
With imprint, transparent cover plate
- Knockouts
2xM20+9xM20/25+1xM25/32
- Length
130 mm
- Width
130 mm
- Height
75 mm
- Content
1 pc(s)
- Type
TK PS 1313-7-tm
- Dim
(L x W x H) 130 x 130 x 75 mm
- Manufacturer part #
10600501
- Material (details)
Polycarbonate (cover plate) / polystyrene (lower box)
- Type
PS 1313-7-tm
Grey
130
130 mm
75 mm
7035
FALSE
0
0
TRUE
FALSE
Other
Plastic
IK07
IP66
FALSE
TRUE
FALSE
FALSE
Untreated
FALSE
FALSE
FALSE
TRUE
Documents & Downloads
Datasheet
Datasheet 530930 Spelsberg TK PS 1313-7-tm Fitting bracket 130 x 130 x 75 Polycarbonate (PC), Polystyrene (EPS) Grey-white (RAL 7035) 1 p
Datasheet 530930 Spelsberg TK PS 1313-7-tm Fitting bracket 130 x 130 x 75 Polycarbonate (PC), Polystyrene (EPS) Grey-white (RAL 7035) 1 p
User & Safety Instructions
User & Safety Instructions 530930 Spelsberg TK PS 1313-7-tm Fitting bracket 130 x 130 x 75 Polycarbonate (PC), Polystyrene (EPS) Grey-white (RAL 7035) 1 p
Description
The TK Series - HP has the high degree of protection IP 66, sealable, and comes standard with either smooth sides or refer to metric knockouts. No subsequent drilling or milling - simply eject knockouts with a screw driver and install the screws For individual holes with smooth sidewalls can easily edit the material. The cases are resistant to scratches. They are characterized by high flexibility, eg through the mounting of accessories as well as the many opportunities in Kasteninneren, the adjusted standard rails and mounting plates. The covers are optionally available in Gray or Transparent . The wall mounting options in the box below the ground and cover screws round out the variety of possible applications.
Hints
Safety-relevant component - installation only by skilled workers
