Stäubli B4-I/KS SW Test lead adapter Terminal - 4 mm socket Rigid Black
EAN:
Part number:
Item no:
Product type
Test lead adapter
Type A
Terminal
Type B
4 mm socket
Reading category
CAT II 1000 V
Factory colour
Black
Datasheet (PDF)
Total (€ 0.45 / piece)
€ 0.45
plus VAT.
14-day return policy included
Technical specifications
- Product type
Test lead adapter
- Type A
Terminal
- Type B
4 mm socket
- Factory colour
Black
- Reading category
CAT II 1000 V
- Jack diameter
4 mm
- Clamping range diameter mm
2/4.1 mm
- Tip material
Brass
- Nominal voltage
1000 V
- Nominal current
20 A
- Shaft length
28 mm
- Tip length
9 mm
- Plug features
Rigid
- Type
B4-I/KS SW
- Nominal voltage (details)
1000 V
- Nominal current (details)
20 A
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 122292 Stäubli B4-I/KS SW Test lead adapter Terminal - 4 mm socket Rigid Black
User & Safety Instructions
User & Safety Instructions 122292 Stäubli B4-I/KS SW Test lead adapter Terminal - 4 mm socket Rigid Black
Information
Information 122292 Stäubli B4-I/KS SW Test lead adapter Terminal - 4 mm socket Rigid Black
Description
Cable Lug adapter from brass for Fixed contact e.g. of screw terminals. Ø 4 mm rigid socket in insulated body, suitable for accepting spring-loaded Ø 4 mm plugs with rigid insulating sleeve. fork once turned up to 90 °.
