StandexMeder Electronics M11/B12 Magnetic reed switch actuator Cylindrical (L x W x H) 38 x 9.85 x 9.85 mm AlNiCo Temper
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 9.24
3
6% = € 0.53
€ 8.71
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 9.24 / piece)
€
Technical specifications
- Housing material: brass
- Type
M11/B12
- Enclosure type
Cylindrical
- Material
AlNiCo
- Temperature limit (max.)
450 °C
- Length
38 mm
- Width
9.85 mm
- Height
9.85 mm
- Dim
(L x W x H) 38 x 9.85 x 9.85 mm
- Type
M11/B12
- Product type
Magnetic reed switch actuator
Documents & Downloads
Datasheet
Datasheet 1382817 StandexMeder Electronics M11/B12 Magnetic reed switch actuator Cylindrical (L x W x H) 38 x 9.85 x 9.85 mm AlNiCo Temper
Description
Magnet in a robust brass housing with threaded sleeves. Is used among other things with the MK 11 (B) Reed Sensor. Robust housing, resistant to high temperatures, moisture and pressure. The sensor (not included) is usually on the fixed part is mounted, the magnet at the moving.
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1x magnet
- 2 x M10 nuts
