Image similar
Image similar
StandexMeder Electronics SIL24-1A72-71D Reed relay 1 maker 24 V DC 0.5 A 10 W SIL 4
EAN:
Part number:
Item no:
Product type
Reed relay
Contact type
1 maker
Enclosure
SIL 4
Connection
Print
Contact material
Iridium
Datasheet (PDF)
532 Piece(s)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 3.61
10
7% = € 0.27
€ 3.34
25
11% = € 0.38
€ 3.23
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 3.61 / piece)
€
Technical specifications
- Product type
Reed relay
- Type
SIL24-1A72-71D
- Contact type
1 maker
- Features
+ protection diode
- Enclosure
SIL 4
- Connection
Print
- Contact material
Iridium
- Nominal voltage
24 V DC
- Resistance (coil)
2000 Ω
- Switching voltage (max.)
200 V AC
- Switching current (max.)
0.5 A
- Max. switching capacity
10 W
- Min. temperature
-20 °C
- Max. temperature
70 °C
- Length
19.8 mm
- Width
5.08 mm
- Height
7.8 mm
- Dim
(L x W x H) 19.8 x 5.08 x 7.8 mm
Documents & Downloads
Datasheet
Datasheet 1382827 StandexMeder Electronics SIL24-1A72-71D Reed relay 1 maker 24 V DC 0.5 A 10 W SIL 4
Description
SIL relays reduce the space required compared with DIP relay by 50%. You have an international standard pin assignment and are thus compatible with almost all the other manufacturers.
