Buy Statron 2225.4 Bench PSU (adjustable voltage) 0 - 35 V 0 - 5 A 375 W No. of outputs 3 x

Datasheet (PDF)

Fast track dispatch on Fri, 11 Sep

4 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 713.45 / piece)

€ 713.45

plus VAT.

Only 4 Piece(s) available

Report legal concerns

Highlights & Details

Laboratory power supply 2225.4

No. of outputs 3 x
0 - 35 V / 0 - 5 A
0 - 35 V / 0 - 5 A
5 V / 5 A
375 W

Technical specifications

Type: 2225.4

Product type: Bench PSU (adjustable voltage)

No. of outputs: 3 x

: 375 W

Dim: (L x W x H) 230 x 360 x 150 mm

: Manufacturer's standards (no certificate)

Weight: 10 kg

Output voltage (max.): 35 V

Output voltage (min.): 0 V

Output voltage 2 (max.): 35 V

Output voltage 2 (min.): 0 V

Output voltage 3 (max.): 5 V

Output voltage 3 (min.): 5 V

Max. output current: 5 A

Output current (min.): 0 A

Output current 2 (max.): 5 A

Output current 2 (min.): 0 A

Output current 3 (max.): 5 A

Output current 3 (min.): 5 A

Width: 360 mm

Height: 150 mm

Length: 230 mm

Documents & Downloads

Datasheet

Datasheet 1425128 Statron 2225.4 Bench PSU (adjustable voltage) 0 - 35 V 0 - 5 A 375 W No. of outputs 3 x

User & Safety Instructions

User & Safety Instructions 1425128 Statron 2225.4 Bench PSU (adjustable voltage) 0 - 35 V 0 - 5 A 375 W No. of outputs 3 x

Description

Multiple voltage source for universal use. Output voltages can in sequence, and can also be connected in parallel. For the exact adjustment of the output data is 10-turn potentiometer is installed. The design as a linear regulators are low ripple and noise voltages. All outputs can simultaneously use.

This text is machine translated.
