Stäubli B4-I/K SW Test lead adapter Terminal - 4 mm socket Black
EAN:
Part number:
Item no:
Product type
Test lead adapter
Type A
Terminal
Type B
4 mm socket
Reading category
CAT II 1000 V
Factory colour
Black
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 6.29
5
6% = € 0.38
€ 5.91
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 6.29 / piece)
€ 6.29
plus VAT.
14-day return policy included
Technical specifications
- Product type
Test lead adapter
- Type A
Terminal
- Type B
4 mm socket
- Factory colour
Black
- Reading category
CAT II 1000 V
- Jack diameter
4 mm
- Clamping range diameter mm
4.2/6.2/8.3 mm
- Tip material
Brass
- Nominal voltage
1000 V
- Nominal current
32 A
- Shaft length
31 mm
- Tip length
24.8 mm
- Type
B4-I/K SW
- Nominal voltage (details)
1000 V
- Nominal current (details)
32 A
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 122288 Stäubli B4-I/K SW Test lead adapter Terminal - 4 mm socket Black
User & Safety Instructions
User & Safety Instructions 122288 Stäubli B4-I/K SW Test lead adapter Terminal - 4 mm socket Black
Information
Information 122288 Stäubli B4-I/K SW Test lead adapter Terminal - 4 mm socket Black
Description
Cable Lug adapter made from brass for firm contacting e.g. of screw clamp Ø 4 mm rigid socket in insulated body, suitable for accepting spring-loaded Ø 4 mm plugs with rigid insulating sleeve.
