Steinel 066147 Twilight switch White 230 V
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Steinel twilight sensor NightmaIQ white design dimmer switch 1000 W
- Automatic lighting at nightInconspicuous and modern designTwilight value can be set from 1 - 75 lxSwitches every bulb with up to 1000 W breaking capacityReliable outdoor function (IP54)
Technical specifications
- Product type
Twilight switch
- Twilight settings
1 - 75 lx
- Operating voltage
230 V
- Self-consumption
0.7 W
- Max. switching capacity
1000 W
- Switching capacity (LED)
250 W
- Switching capacity (light tubes)
250 W
IP54
- Factory colour
White
- Dim
(L x W x H) 38 x 95 x 95 mm
- Length
38 mm
- Width
95 mm
- Height
95 mm
- Depth
38 mm
240 V
Surface mounted (plaster)
White
95
95 mm
38 mm
Other
Other
Plastic
-20-40 °C
FALSE
Matt
IP54
FALSE
FALSE
FALSE
FALSE
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2845668 Steinel 066147 Twilight switch White 230 V
User & Safety Instructions
User & Safety Instructions 2845668 Steinel 066147 Twilight switch White 230 V
User & Safety Instructions 2845668 Steinel 066147 Twilight switch White 230 V
Warranty Terms
Warranty Terms 2845668 Steinel 066147 Twilight switch White 230 V
Description
The conspicuous inconspicuous twilight switch NightmatIQ impresses through a flat straight design and provides for a perfect lighting automatically night after night. With reaching the adjusted twilight threshold the twilight switch takes its work and switches on all connected lamps simultaneously (max. 1000 W, 250 W LED). Thus house fronts, lands, gardens, shop windows or other areas can be illuminated reliably punctually for twilight - without having to touch only one finger for this. When hours later the morning turns off, the lights turn off on their own. Thus the existing lights that were previously switched manually can be changed over to automatic operation in no time at all thanks to NightmatIQ. The dimmer value is adjusted by potentiometer (controller) as required from 1 to 75 lux ambient brightness. Whether rain, storm or snow – the NightmatIQ operates reliably in any weather thanks to the IP 54 protection class. The twilight switch is available in white and anthracite colors.
This text is machine translated.
This text is machine translated.
Features
- Light sensor
Scope of delivery
- Installation material (2x dowel, 2x screw, 2x sealing plugs)
Hints
The mains cable can be connected in-wall as well as on the surface at the twilight sensor. For surface mounting, carefully break out the pre-punched holes at the bottom of the housing, insert the supplied sealing plugs and feed the cable through the plugs into the device.
