Image similar
Image similar
Stiebel Eltron UP 25/7,5 PCV Circulation pump 4 m³/h 10 bar
EAN:
Part number:
Item no:
Technical specifications
- Protection class (IP): IPX4
- Number of phases: 1
- Rated voltage: 230 V
- Mains frequency: 50/60 Hz.
- Cable length: 1.5 m
- Ambient temperature -10..110°C
- Wireless standard 5G: No
- Supports protocol for PROFIBUS: No.
- Supports protocol for KNX: No.
- Supports protocol for PROFINET IO: No.
- Supports protocol for Ethernet/IP: No.
- Wireless standard Bluetooth: No.
- Wireless standard WLAN 802.11: No.
- Mounting length 180 mm
- Electrical connection: Other
- Flange shape: Other
- Max. Operating pressure 10 bar
- Pump housing material: Cast iron
- Material quality of pump housing: Other
- Material of blower wheel/impeller: Other
- Material quality Blower wheel/impeller: Other
- Pump circuit: Other
- Interface signal 0-20 mA / 4-20 mA: No.
- Interface PT100 / PT1000 / PTC: No.
- Pulse counter interface: No.
- Supports protocol for CAN/CANopen: No.
- Supports protocol for Modbus TCP: No.
- Supports protocol for Modbus RTU: No.
- Supports protocol for BACnet MS/TP: No.
- Supports protocol for BACnet IP: No.
- Supports protocol for LON/LonWorks: No.
- Supports protocol for LIN Bus: No.
- Inlet side connection: Other
- Pressure stage flange connection inlet: Other
- Connection standard Inlet side: Other
- Outlet side connection: Other
- Pressure stage flange connection outlet side: Other
- Connection standard outlet side: Other
- Type of speed control: Infinitely variable
- Volume flow delivery height (BEP): 8.4 kPa
- Max. Pump volume: 4 m³/h.
- Max. lifting height 8.4 m
- Double pump: No.
- Energy efficiency class (EEI): 0.2
- Insulation class IEC F
- Wireless standard 2G: No
- 3G wireless standard: No.
- 4G wireless standard: No.
- With RS-485 communication interface: No.
- With RS-232 communication interface: No.
- Diameter, inlet side connection: Other
- Nominal diameter, outlet side connector: 1 1/2 in. (40)
- DVGW seal for water: No.
- Product type
Circulation pump
- Operating voltage
230 V
- Pressure connection
38 mm (1 1/2") Ø
- Max. operating pressure
10 bar
- Max. feed rate
4 m³/h
- Max. delivery head
8.4 m
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3549349 Stiebel Eltron UP 25/7,5 PCV Circulation pump 4 m³/h 10 bar
Description
Description
The heating circulation pump is particularly energy-efficient since both an electronic power control for conveying the heat carrier as well as an infinitely variable differential control are integrated.
This text is machine translated.
The heating circulation pump is particularly energy-efficient since both an electronic power control for conveying the heat carrier as well as an infinitely variable differential control are integrated.
