Studer Grid-tie inverter AJ 1000-12-S 1000 W 12 V DC - 230 V AC
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Inverter AJ 1000-12-S
- Built-in PWM charge controller
- High degree of efficiency
- Large overload capacity thanks to a ring core transformer
Technical specifications
- Max. voltage 25 V
- Max. charging current: 25 A
- 3 levels (I/U/Uo) Swing Bella fertilizer
- Absorption voltage 14.4 V
- Hover charging voltage 13.6 V
- Reverse polarity protection 125 A
- Protection Artz IP30
- Current consumption: 10 W
- Temperature range: -20 to +50 °C
- Load detection 1, 20 W adjustable
- Noise level< 45 dB
- Input voltage
10.5, 16 V
- Product type
Grid-tie inverter
- Signal output type
Sine wave
- Output voltage
230 V AC
1000 W
- Input voltage
12 V DC
- Inputs
Cable
- Output
open ends
- Nominal load efficiency
93 %
- Output frequency
50 - 60 Hz
- Weight
8.5 kg
- Cooling method
Fan
- Width
428 mm
- Height
142 mm
- Depth
84 mm
- Peak output power
2200 W
- Standby consumption
0.7 W
- Type
AJ 1000-12-S
Documents & Downloads
Datasheet
Datasheet 1667015 Studer Grid-tie inverter AJ 1000-12-S 1000 W 12 V DC - 230 V AC
User & Safety Instructions
User & Safety Instructions 1667015 Studer Grid-tie inverter AJ 1000-12-S 1000 W 12 V DC - 230 V AC
Information
Information 1667015 Studer Grid-tie inverter AJ 1000-12-S 1000 W 12 V DC - 230 V AC
Description
Studer AJ-S inverter offers high quality and reliability!
The sine inverter converts the DC voltage from, for example, a battery in a for all electrical devices suitable sine AC voltage. Compact design, low power consumption, as well as the effective battery protection function.
Compared with a DC power system is an alternating current system in solar power systems from a power of 100 W more efficient. Because of the high overload capacity and its reliable standby system is the AJ the most suitable inverter type for the technical and economic needs of small solar power supplies.
The AJ-S inverter is specially designed for use with solar modules. The shunt charge controller works on the principle I/U/Uo with hover charging device and thus ensures the best charging and battery life. The function of the charge controller is displayed with the orange LED is displayed.
This text is machine translated.
The sine inverter converts the DC voltage from, for example, a battery in a for all electrical devices suitable sine AC voltage. Compact design, low power consumption, as well as the effective battery protection function.
Compared with a DC power system is an alternating current system in solar power systems from a power of 100 W more efficient. Because of the high overload capacity and its reliable standby system is the AJ the most suitable inverter type for the technical and economic needs of small solar power supplies.
The AJ-S inverter is specially designed for use with solar modules. The shunt charge controller works on the principle I/U/Uo with hover charging device and thus ensures the best charging and battery life. The function of the charge controller is displayed with the orange LED is displayed.
This text is machine translated.
Features
- Built-in PWM charge controller
- High degree of efficiency
- Large overload capacity thanks to a ring core transformer
- Adjustable load detection (stand-by)
- Microprocessor-controlled
- Power electronics with MOSFETs
- Overcharge protection
- Temperature control
- Circuit breaker
- Reverse polarity protection
- Built-in battery protection function
- Function for optimizing the battery life (B. L. OR SIMILAR)
- Plug&Forget solution
- Alarm
- Automatic restart
- Meets numerous standards
- LED display
Scope of delivery
- Inverter
- Battery connection cable approx. 1.2 m
- AC cable approx. 1 m
- User manual.
