Sunon DP202A-2123MBT.S.GN Axial fan 230 V AC 134.18 m³/h (L x W x H) 38 x 120 x 120 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
230 V AC
Power
9.9 W
Type of bearing
Ball bearing
Air flow rate
134.18 m³/h
Datasheet (PDF)
Technical specifications
- Connection type: Integrated spade connectors (2.8x0.5mm)
- Product type
Axial fan
- Type
DP202A-2123MBT.S.GN
- Nominal voltage
230 V AC
- Min. operating voltage
185 V AC
- Max. operating voltage
245 V AC
- Operating voltage
185 - 245 V AC
- Max. current consumption
0.057 A
9.9 W
- Type of bearing
Ball bearing
- Rotational speed
2400 U/min
- Noise emission (max.)
42 dB
- Air flow rate
134.18 m³/h
- Connection
Type C CEE 7/16 plug 2.8 mm
- Pressure (max.)
34.86 Pa
- Factory colour
Black
- Material
Aluminium (die-cast)
Thermoplastic
- Weight
480 g
- Min. temperature
-10 °C
- Max. temperature
70 °C
- Length
38 mm
- Width
120 mm
- Height
120 mm
- Dim
(L x W x H) 38 x 120 x 120 mm
