Sunon EE60251B3-000U-A99 Axial fan 12 V DC 23.61 m³/h (L x W x H) 25 x 60 x 60 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
12 V DC
Power
0.6 W
Type of bearing
Ball bearing
Air flow rate
23.61 m³/h
Datasheet (PDF)
Technical specifications
- Connection type: UL1007 AWG26 wires, stripped, tin-plated
- Product type
Axial fan
- Type
EE60251B3-000U-A99
- Nominal voltage
12 V DC
- Min. operating voltage
6 V DC
- Max. operating voltage
13.8 V DC
- Operating voltage
6 - 13.8 V DC
- Max. current consumption
0.05 A
0.6 W
- Type of bearing
Ball bearing
- Rotational speed
3000 U/min
- Noise emission (max.)
20 dB
- Air flow rate
23.61 m³/h
- Connection
Braid
- Pressure (max.)
19.92 Pa
- Factory colour
Black
- Material
Thermoplastic
70000 h
- Weight
50 g
- Min. temperature
-10 °C
- Max. temperature
70 °C
- Length
25 mm
- Width
60 mm
- Height
60 mm
- Dim
(L x W x H) 25 x 60 x 60 mm
