Sunon EF80251B3-1000U-A99 Axial fan 12 V DC 56.05 m³/h (L x W x H) 25 x 80 x 80 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
12 V DC
Power
0.78 W
Type of bearing
Ball bearing
Air flow rate
56.05 m³/h
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 6.29
5
6% = € 0.38
€ 5.91
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 6.29 / piece)
€ 6.29
plus VAT.
14-day return policy included
Technical specifications
- Connection type: Strands UL1007 AWG24, stripped, tin-plated
- Product type
Axial fan
- Type
EF80251B3-1000U-A99
- Nominal voltage
12 V DC
- Min. operating voltage
4.5 V DC
- Max. operating voltage
13.8 V DC
- Operating voltage
4.5 - 13.8 V DC
- Max. current consumption
0.065 A
0.78 W
- Type of bearing
Ball bearing
- Rotational speed
2600 U/min
- Noise emission (max.)
28 dB
- Air flow rate
56.05 m³/h
- Connection
Braid
- Pressure (max.)
27.39 Pa
- Factory colour
Black
- Material
Thermoplastic
70000 h
- Weight
101.8 g
- Min. temperature
-10 °C
- Max. temperature
70 °C
- Length
25 mm
- Width
80 mm
- Height
80 mm
- Dim
(L x W x H) 25 x 80 x 80 mm
