Sunon MF25100V21000UA99 Axial fan 5 V DC 5.09 m³/h (L x W x H) 25 x 25 x 10 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
5 V DC
Power
0.33 W
Type of bearing
Vapo (magnetic)
Air flow rate
5.09 m³/h
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 10.08
3
6% = € 0.58
€ 9.50
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 10.08 / piece)
€ 10.08
plus VAT.
14-day return policy included
Technical specifications
- Product type
Axial fan
- Type
MF25100V21000UA99
- Nominal voltage
5 V DC
- Max. operating voltage
5 V
- Operating voltage
5 V (max)
- Max. current consumption
65 mA
0.33 W
- Type of bearing
Vapo (magnetic)
- Rotational speed
9800 U/min
- Noise emission (max.)
16 dB
- Air flow rate
5.09 m³/h
- Connection
Open end cable
- Cable length
0.15 m
- Material
Thermoplastic
PBT
- Min. temperature
-10 °C
- Max. temperature
+70 °C
- Length
25 mm
- Width
25 mm
- Height
10 mm
- Dim
(L x W x H) 25 x 25 x 10 mm
Documents & Downloads
Datasheet
Datasheet 2357971 Sunon MF25100V21000UA99 Axial fan 5 V DC 5.09 m³/h (L x W x H) 25 x 25 x 10 mm
